93-530-70 Issue 0 Page 19 of 44 © Protec Fire Detection PLC 2007

Access Level 3 (Engineer Controls)

Only engineers are permitted access to level 3 functions, these are:

• All level 2 functions, plus

• The setting of zone delay times.

• The programming of delayed zones.

• The programming of coincidence zones.

• The programming of non-latching zones.

• The programming of test zones (one, or more zones may be programmed).

• The programming of expansion interface data.

• Fault diagnosis features.

• Programming the end of line type.

• Programming the power supply type.

13.2 Zone Programming Choices

Each zone of the 3300 may be programmed in the following manner.

• Non-latching mode.

• Coincidence mode.

• Delay mode.

• Test mode.

Please not that a zone can only be programmed with one of the choices (ie. a zone cannot be set-up

as non-latching and delay) the last programmed choice will be accepted by the 3300.

NOTE: Test mode overrides all other programming.
