14.2 Programming Alarm Disablements
The 3300 can have alarm circuits 1 and 2 and/or alarm circuits 3 and 4 disabled. When an alarm
circuit is disabled faults and activations on that circuit are inhibited.
1. From access level 1 enter your 5 digit user code 1 3 4 4 2 or turn the key-switch (depending on
the model purchased).
2. The ‘Level 2 Accessed’ indicator will illuminate.
3. Using button 2 scroll to the ‘Alarm Outputs’ indication. Any current alarm disablements will be
displayed on row 1 of the display. Accept this option by pressing button 3.
4. The ‘Alarm Outputs’ indicator will flash, showing this option has been accepted.
5. Highlight the alarm circuit pair to be disabled by pressing button 2
• Highlight zone 1 indicator if alarm circuits 1 and 2 are to be disabled.
• Highlight zone 2 indicator if alarm circuits 3 and 4 are to be disabled.
Note: Zone 3 and zone 4 indicators can also be selected in this option. See sections 15.0
and 16.0 for details
6. Press button 1 to show that it is to be disabled / not disabled. If the alarm circuit is disabled the
relevant row 1 indicator will be illuminated.
7. Press button 3 to return to the selection menu.
8. Press button 4 to accept and program the disablement set-up and return to access level 2.
9. The yellow ‘General Disablement’ indicator will be illuminated steady, as will the yellow ‘Alarm
Outputs’ indicator.
