1.0 3300 System Overview

The main features of the Protec 3300 Fire Alarm system are:

• Four and eight detector zone models available.

• Four monitored alarm circuits rated at 150mA each.

• Common negative (allowing three wire operation).

• Manual call point activation can override zone delays.

• Re-sounding of outputs if a zone changes from automatic to manual activation.

• Three auxiliary inputs, Keyswitch, Class Change and Remote Alarm.

• Global Fire and Global Fault clean contact connections.

• Monitored Auxiliary 24V output (Overload Protected, 100mA maximum).

• Programmable capacitive or resistive detector circuit end of line monitoring.

• Extensive range of engineering functions, accessed via a 5 digit code entry or key-switch

activation.

• Delays to zones.

• Disablement of zones.

• Coincidence Operation.

• testing of zones.

• Non-latching zones.

• Disablement of alarm circuits.

• Disablement of fire link output.

• Comprehensive fault diagnosis features.

• Expansion outputs to drive one fire link interface and one eight way zonal mimic interface.

• Repeat panel output to drive up to eight 3300 Repeat Panels, no extra driver board is required.

• All interfaces supported as standard.

• Low quiescent current of 15mA (24V dc supply, mains fail fault, no external equipment).

Note: Due to a policy of continuous improvement Protec Fire Detection PLC reserve the right to alter

the specification without prior notice.
