Pulsafeeder PULSAblue 3300 Series User Manual

13
Refer to the drawing in the back of this manual for wiring instructions.
8.6 Node Wiring
If optional nodes are ordered they must be wired to the controller before installation and programming
can take place. Nodes require +24 VDC for operation and twisted pair wire for data transmission. The
network interface option card can provide the +24 VDC for up to two nodes using non-twisted pair wire.
If using three or more nodes an external +24 VDC power supply run in parallel is recommended.
Recommended twisted pair for data specifications are:
Beldon 85102, single twisted pair, stranded 9/29, unshielded, plenum.
Beldon 8471, single twisted pair, stranded 9/29, unshielded, nonplenum.
JY (ST) Y 2 X 2 X .8, UL Level IV 22 AWG, twisted pair, typically solid and unshielded.
Four wire helical twist, solid, shielded.
If shielded cable is used, the shield should be connected to earth ground via a 470K ohm, .25 watt,
metal film resistor to prevent static charge buildup.
Nodes are wired directly to the NIN card inside the controller enclosure.
Please refer to the diagram in the back of this manual for wiring instructions.
9 Functional Overview
9.1 Front Panel
Figure 2: Model 3300 Front Panel with Display
