41
To set up the com port press ―1‖ COM PORT SETUP
COM PORT PARAMETERS
=======================
BAUD RATE: 19200
DATA BITS: 8
STOP BITS: 1
PARITY : NONE
<UP><DOWN> ENT: ACCEPT
Use the arrow keys to change the baud rate. If using the direct connect method of communicating,
ensure that the baud rate at the controller and the baud rate in the LRWS software match.
The standard values for the DATA BITS is 8, STOP BITS is 1, and PARITY is NONE. Normally these
will not need to be changed.
18.11 Initialize Modem
Before a modem can be used by the controller it must be initialized. The initialization screen gives four
choices of modems.
To initialize the modem:
From the Communications menu, press ―2‖ INITIALIZE MODEM
INITIALIZE MODEM
=======================
1 HAYES ACCURA
2 U.S. ROBOTICS
3 ZOOM
4 OTHER MODEM
Select your modem from the list. If your modem is not listed and you select OTHER MODEM use
the keypad to enter the initialization string for your modem.
If the modem fails to initialize, check the 25-pin connector, the phone cable, the modem, and the RS-
232 option card.
18.12 Remote Password
Remote communications to the Pulsafeeder 3300 series controllers is protected with an 8-digit
password. The remote password is required to make changes to the controller using the
communications option card.
The remote password screen in the communications menu is used to change the remote password. The
remote password can only be changed at the controller.
To change the remote password:
From the communications menu, press ―3‖ REMOTE PASSWORD.
Use the keypad to enter the old password. Enter the new password. Repeat the new password
again for verification. NOTE: The default password is 12345678.
Set the remote password in the LRWS program to match the new password for this controller.
