8
Has expansion slots to add additional control, such as additional relay outputs, 4-20 mA outputs, remote
sensor inputs, digital inputs, and 4-20 mA inputs.
5.3 Specifications
Conductivity range
0-5000 µS
Conductivity Accuracy
± 40 µS
Conductivity Resolution
10 µS
ORP range
-1000 to + 1000 mV
ORP Accuracy
± 5.0 mV
ORP Resolution
1 mV
Accuracy & Repeatability
± 1.0% of scale
Deadband/Setpoint
User programmable
Auto/Manual outputs
Menu selectable
Keypad
16 - key push buttons
Display
Illuminated 128 x 64
pixel LCD
Water meter inputs (2)
Contact head, paddle wheel or turbine.
Output relays
1 Bleed off
3 selectable use
Relay ratings
3A each, 10A total
Power
120/240 VAC 50/60 Hz 6W
Ambiant temp
32° - 158°F (0 - 70°C)
Storage temp
32° - 158°F (0 - 70°C)
Max. Water temperature
140°F
Max. water pressure
140 psi @ 100°F
Languages
Selectable:
English, plus one of:
Spanish
German
French
Enclosure
NEMA 4X
