22
5 WATER METERS
6 4-20 MA IN/OUT
7 SYSTEM SETUP
8 CLOCK
The MAIN MENU can be accessed from the PROCESS screen by pressing ―BACK‖. If ―BACK‖ is
pressed and the MAIN MENU does not appear, the controller is probably in the VIEW ONLY or
OPERATOR security mode. If the controller is in the VIEW ONLY or OPERATOR security mode, enter
the TECHNICIAN security password to be able to access the MAIN MENU.
To move about in the menu screen use the and keys to highlight the desired option and press
―ENT‖ or simply press the number key for the desired option.
Use the ―ENT‖ key to accept a setting or to enter a screen. Use the ―BACK‖ key to reject a setting or to
exit a screen. From anywhere in the menu, pressing ―BACK‖ will take you one step closer to the MAIN
MENU.
Certain menu items are only visible if certain conditions apply, such as: nodes are installed, or
other parameters are configured. If a menu item does not appear in the menu it most likely
means that the option is not installed or configured.
Each of the MAIN MENU options are discussed in detail later in this manual.
13.1 Configuring the Relays
To access the relay configuration screen from the MAIN MENU, press ―2‖ or highlight RELAYS
and press ―ENT‖. The following screen will appear.
WHICH RELAY?
============
1 BLOW
2 RLY2
3 RLY3
4 RLY4
Select the relay that you want to program.
13.1.1 Configuring the Blowdown Relay
Below is the RELAY OPTIONS screen. The asterisk (*) next to one of the options tells you how that
relay is configured.
