Pulsar® Precision Operaon and Installaon Manual (Model PS-1HCE) Rev 2.0 04/2022
24
10 Appendix
10.1 RequirementsandSpecicaons
10.1.1 RequirementsforProductInstallaonandOperaon
Table5. SiteRequirement
RecommendedClearance Feeder: 48" L x 48" W x 76" H [121.9 cm x 121.9 cm x 193.0 cm]
MinimumClearance Feeder: 36" L x 36" W x 64" H [91.4 cm x 91.4 cm x 162.6 cm]
Electrical 120/240 V AC, 1 ph, 50/60 Hz, 15 - 20 A
Table6. AccessoryRequirements
Chemical Pulsar® Plus Briquees
DischargeTubing 1/2” [1.27 cm] OD Polyethylene exible tubing
WaterInletTubing 1/2” [1.27 cm] OD Polyethylene exible tubing
10.1.2 ProductSpecicaons
Table7. OperaonalSpecicaons
DryChemicalCapacity 100 lbs + 50 lbs reserve [45.4 kg + 22.7 kg reserve] (102 lbs [46.3 kg] of available chlorine)
TankSize(SoluonVolume) 6.3 gal [23.6 L]
AvailableWorkingSoluon 4.8 gal [18.2 L]
WaterInletSize 1/2" [1.3 cm] OD
SoluonOutlet 1/2" [1.3 cm] OD
ShippingWeight Approximately 70 lbs [31.8 kg]
OperangWeight Approximately 220 lbs [100 kg]
OperangTemperature 40 °F – 95 °F [4.4 °C – 40.6 °C]
FeederDimensions 29.8" L x 25.3" W x 40.9" H [75.7 cm x 64.3 cm x 103.9 cm]
FeederCable 9' [2.7 m]
ControlBoxDimensions 7.95” W x 4.8” H x 2.9 D [20.2 cm x 12.2 cm x 7.4 cm]
ControlBoxPowerCable 10’ [3 m]
ControlBoxFeederCable 1’ [0.3 m]
ControlBoxORPCable 20’ [6 m]
ControlBoxFlowSwitchCable 33’ [10 m]
Table8. ChemicalFeedRateSpecicaons
ChlorineDeliveryRate(Pools) 5 – 189 lbs [2.3 kg – 85.7 kg] AvCl/day
Maximum of 7.8 lbs [3.5 kg] AvCl/hr
ChlorineDeliveryRate(Spas) 5 – 141 lbs [2.3 kg – 63.9 kg] AvCl/day
Maximum of 5.9 lbs [2.7 kg] AvCl/hr
