Pulsar PS-1HCE User Manual

Pulsar® Precision Operaon and Installaon Manual (Model PS-1HCE) Rev 2.0 04/2022
8
3 Pulsar® Precision Feeder Overview
Figure3. Front View of Pulsar® Precision Feeder
A4
B2
A5
A6
A1
B1
A2
A3
A
B
3.1 Components List
The Pulsar® Precision Feeder includes these components:
A Hopper, which includes:
A1 Hopper lid, hinge pin, and retainer
A2 HCE grid basket
A3 HCE bowl
A4 Juncon Box
A5 Front cover
A6 Feeder control box
A7 ESV (emergency shuto valve)(picture not shown)
A8 ESV nut wrench (picture not shown)
A9 Grid basket removal tool (picture not shown)
B Base, which includes:
B1 Le and right covers
B2 Discharge valve assembly
B3 Level switch (picture not shown)
B4 Bucket funnel (picture not shown)
C Booster pump and venturi installaon kit (picture not shown)

Pulsar PS-1HCE Specifications

General

Brand	Pulsar
Model	PS-1HCE
Category	Swimming Pool Filter
Language	English
