Pylontech PowerCube-H1-V2 - Annex 2: System Turn off Progress List

3
Turn off the switch between PCS and this battery string
(PowerCube-H1/H2-V2), or turn off the power switch of PCS, to
make sure no current through this battery string.
Refer to chapter 3.8
Refer to chapter 3.8
2
Turn off all the “Power Switch” of the Control Module.
Refer to chapter 3.8
1
Soft-off the PCS through PCS’s control panel.
No. RemarkItem
Tick after
completion
13
If the system need black start, long press the start button 30
seconds after power on. System will close relays and output for
10 minutes.
Refer to chapter
3.7
12
The first installation should do full charging progress.
After Master controller has communicated with each
slave BMS, it will run parallel operation. It will begin from
lowest voltage battery string to do the parallel operation
during the charging.
If the status LED of BMS turns to green, it means this
battery string is in parallel operation.
No. RemarkItem
Tick after
completion
The first
installation
should do full
charging
progress.
Annex 2: System Turn OFF Progress List
