Pylontech PowerCube-H1-V2 - System Diagram; System Diagram Via CAN

USB
Multiple battery string parallel connection via CAN communication among BMSs diagram (battery string
qty. ≤6 sets). The Battery Controller with ADD address 1 is the master and all remaining Battery Control-
lers are the slave. The external interface is only valid on the Battery Controller with ADD address “1”.
USB is used for product updating and data downloading.
WIFI
Support for the Cloud platform functions.
Manufacturer: Pylon Technologies Co., Ltd.
Address: Plant 8, No.505 Kunkai Road, JinXi Town, 215324 Kunshan City, Jiangsu Province, PEOPLE'S
REPUBLIC OF CHINA
Importer: XXXX （Located in installed country）
Address: XXXX （Located in installed country）
Wireless maximum output power: 20dBm
Operating frequency: 2412-2472MHz
Gain of antenna: Max 3dBi
Modulation system：
DBPSK/DQPSK/CCK(DSSS)
BPSK/QPSK/16QAM/64QAM(OFDM)
Modulating Repetition：
1Mbps/2Mbps/5.5Mbps/11Mbps(DSSS)
6Mbps/9 Mbps/12 Mbps/18 Mbps/24 Mbps/36 Mbps/48 Mbps/54 Mbps(OFDM)
MCS0~MCS7(802.1 1n 20MHz)
MCS0~MCS7(802.1 1n 40MHz)
Channel spacing:5MHZ
Type of antenna: 2.4G IPEX-SMA Antenna
2.6.1. System Diagram via CAN
2.6. System Diagram
Caution: When an MBMS does not exist, one of the V2 version control modules can be used
as a battery control core to communicate externally with the PCS and internally to control the
other control modules (V2 version or V1 version). When both V2 and V1 versions of the
control module exist, the V2 version of the control module must be used as the master.
