Pylontech PowerCube-X1-V2 User Manual

12
Power Terminal B+/B-
To connect battery module power cables in series.
Power Switch
Switch the battery system’s (control module and high voltage DC
power) ON/OFF.
Caution: When the breaker is tripped off because of over
current or short circuit, must wait after 30mins to turn
on it again, otherwise may cause the breaker damage.
External Power Terminal D+/D-
Connect battery system with Power Conversion System.
Dry Contact Terminal
Dry Contact Terminal: provided 2 input and 4 output dry contact
signal.
In/out
Function
Open and close state
In1
Internal Using ONLY
For wake up signal serial connection
using ONLY.
In2
For wake up or
For Emergency Stop
signal
Always close, when open will switch off
the system.
Out1
Stop Charge
Always close, when open shall stop
charge.
Out2
Stop Discharge
Always close, when open shall stop
discharge.
Out3
Error
Always close, when open shall stop
operation
Out4
Current Limit
Always close, when open shall limit
current to ≤0.2C-rate
Reset
Reset Button: Long press this button to restart the battery system.
ADD
ADD Switch is a 6 bit dial switches to manually
distribute the communication address of the battery
system. Downward position is OFF, means “0”. Upward
position is ON, means “1”. For battery controller, 1st bit to 5th
bit is for address allocation, and the 6th bit dial switch support
a 120Ω resistance (Terminal Resistance), the upward position(ON) of
the 6th bit means access the resistance, and the downward
position(OFF) means no access resistance. The terminal resistance
needs to be activated ON at the first and last node.
Start Button
Start function: press more than 5sec until the buzzer rings,
to turn on controller.
