During
start-up
Normal
Flash2
Off
Flash2
Power On Device
BlackStart
Success
Flash5
Off
Off
Black Start Function
Fail
Off
Flash5
Off
Waiting
Flash5
Off
Flash5
USB
Misc
Update
Flash2
Off
Fla
sh2
Off
Off
Off
Misc/Update(Before
Forceup)
Event
Update
Flash2
Off
Flash2
Off
Off
Event/Update(M2SING)
History
Update
Flash2
Off
Flash2
Off
History/Update(Updating)
Info
Update
Flash2
Off
Flash2
Info/Update(Finished)
Note: The flashing instructions,
flash 1 - 0.25s light / 3.75s off;
flash 2 - 0.5s light / 0.5s off;
flash 3 - 0.5s light / 1.5s off;
flash 4 - 1s light / 1s off;
flash 5 – 0.1s light / 0.1s off;
WIFI
Support for the Cloud platform functions.
Manufacturer: Pylon Technologies Co., Ltd.
Address: Plant 8, No.505 Kunkai Road, JinXi Town, 215324 Kunshan
City, Jiangsu Province, PEOPLE'S REPUBLIC OF CHINA
Importer: XXXX （Located in installed country）
Address: XXXX （Located in installed country）
Wireless maximum output power: 20dBm
Operating frequency: 2412-2472MHz
Gain of antenna: Max 3dBi
Modulation system：
DBPSK/DQPSK/CCK(DSSS)
BPSK/QPSK/16QAM/64QAM(OFDM)
Modulating Repetition：
1Mbps/2Mbps/5.5Mbps/11Mbps(DSSS)
6Mbps/9 Mbps/12 Mbps/18 Mbps/24 Mbps/36 Mbps/48 Mbps/54 Mbps(OFDM)
MCS0~MCS7(802.1 1n 20MHz)
MCS0~MCS7(802.1 1n 40MHz)
Channel spacing:5MHZ
Type of antenna: 2.4G IPEX-SMA Antenna
USB
USB is used for product updating and data downloading.
