14
External 12VDC power supply for the Battery Controller.
Status and SOC Indicators
Status light: to show the battery module’s status (RUN●, Alarm●).
SOC(Battery capacity indicator): 4 green lamps, each light
represents 25% capacity.
Status and SOC Indicators Instructions
Protection
/ Alarm /
Normal
Indicates Sleep Mode, to
save the power.
Indicates save power mode.
Indicates the battery
voltage or temperature is
high or low.
Indicates the battery
voltage or temperature is
over or under.
The highest capacity
indicator LED flashes
(flash 2), others
lighting
The highest capacity
indicator LED flashes
(flash 2), others lighting,
horse race lamp when SOC＞=
DODH;
Stop charging, STATUS(red)
lighting
Indicate based on
capacity
Indicate based on capacity
Stop discharging,
STATUS(red) lighting
Stop charging/discharging,
STATUS(red) lighting
