Pylontech PowerCube-X1 User Manual

7
2.2.1 The parameter of system
Product Type
PowerCube-X1-48/zzzV
PowerCube-X2-48/zzzV
(zzz=96~528, in step of 48)
(zzz=96~528, in step of 48)
Product Name
LFP Lithium Ion Energy Storage
System
LFP Lithium Ion Energy
Storage System
Cell Technology
Li-ion(LFP)
Li-ion(LFP)
Battery System Capacity(kWh)
2.4 × n
(where n = 2~10)
3.552 × n
(where n = 2~10)
Battery System Voltage(Vdc)
48 × n
(where n = 2~10)
48 × n
(where n = 2~10)
Battery System Capacity(AH)
50Ah
74Ah
Battery Controller Name
SC0500-100
SC0500-100
Battery Module Name
H48050
H48074
Battery Module Quantity(pcs)
n (where n = 2~10)
n (where n = 2~10)
Battery Module Capacity(kWh)
2.4
3.552
Battery Module Voltage(Vdc)
48
48
Battery Module Capacity(AH)
50
74
Battery Module Cell Series
Quantity(pcs)
15
15
Battery System Charge Upper-
Voltage(Vdc)
54 × n
(where n = 2~10)
54 × n
(where n = 2~10)
Battery System Charge/Discharge
Current(Standard)
10
14.8
Battery System Charge/Discharge
Current(Normal)
25
37
Battery System Charge/Discharge
Current(Max)
50
74
Battery System Discharge lower-
Voltage(Vdc)
43.5 × n
(where n = 2~10)
43.5 × n
(where n = 2~10)
Short circuit rating
＜4000
＜4000
Efficiency(@0.5C-rate)
96%
96%
Depth of Discharge
90%
90%
Dimension(W*D*H,mm)
600mm(W)*505mm(D)*1300mm
(H) (where n = 2~8), or
600mm(W)*505mm(D)*2130mm
(H)
(where n = 2~10)
600mm(W)*505mm(D)*2130m
m(H)
(where n = 2~10)
Communication
MODBUS RTU\CAN
MODBUS RTU\CAN
Protection Class
IP20
IP20
Weight (kg)
Rack 1: 58kg+ 24kg×n (where n
= 2~8),
Or Rack2: 77kg+ 24kg×n
(where n = 2~10),
77kg+ 32kg×n
(where n = 2~10)
