Pylontech PowerCube-X1 User Manual

14
LED Indicators Instructions
Battery
Statues
Protection /
Alarm /
Normal
RUN
ALM
PRC
Capacity SOC
Descriptions
●
●
●
●
●
●
●
Shut Down
Off
Off
Off
Off
Off
Off
Off
All off
Sleep
Normal
Flash1
Off
Off
Off
Off
Off
Off
Indicates Sleep Mode, to
save the power.
Standby
Normal
Flash1
Off
Off
Off
Off
Off
Off
Indicates Standby mode.
Alarm
Off
Light
Off
Off
Off
Off
Off
Indicates the battery is low or
high
Charge
Normal
Light
Off
Off
The highest capacity
indicator LED flashes (flash
2), others lighting
The highest capacity
indicator LED flashes (flash 2),
others lighting
Alarm
Off
Light
Off
Protection
Off
Off
Light
Off
Off
Off
Off
Stop charging, PRC lighting
Discharge
Normal
Flash3
Off
Off
Indicate based on capacity
Indicate based on capacity
Alarm
Off
Light
Off
Protection
Off
Off
Light
Stop discharging, PRC lighting
Abnormal
Protection
Off
Off
Light
Off
Off
Off
Off
Stop charging/discharging,
PRC lighting
Note: The flashing instructions, flash 1 –0.25s light / off 3.75 seconds; flash 2 - 0.5s light / 0.5s off; flash
3 - 0.5s light / 1.5s off.
2.3 System Diagram
2.3.1 Multiple battery string parallel connection via CAN communication between MBMS and BMS
diagram (battery string qty. ≤6 sets)
