Pylontech PowerCube-X1 User Manual

41
Annex 2: Installation and System Turn ON Progress List
Tick after
completion
No.
Item
Remark
☐
1
The environment is meeting all technical requirements.
3.3.1 Cleaning
3.3.2 Temperature
3.3.3 Radiating System
3.3.4 Heating System
3.3.5 Fire-extinguisher System
3.3.6 Grounding System
Refer to chapter
3.3
☐
2
Battery rack is installed follow the technical
requirements.
Refer to chapter
3.5.3.
☐
3
Control Module (BMS) and Battery Module are installed
well.
Refer to chapter
3.5.4.
☐
4
The MBMS are installed well. (If configured.)
Refer to chapter
3.5.5.
☐
5
Connect External Power Cable +/- between each BMS
to the PCS or confluence cabinet.
Refer to chapter
3.6.2.
☐
6
Connect power cables of each battery string.
Refer to chapter
3.6.2.
☐
7
Connect communication cables of each battery string.
Refer to chapter
3.6.2.
☐
8
Set up ADD switch of every BMS and the MBMS (Address
Assignment).
Refer to chapter
3.6.3.
☐
9
Connect external communication cables from BMS to
BMS, MBMS, inverter, PCS or another.
Refer to chapter
3.6.2.
☐
10
Connect the communication cable from MBMS to the
PCS.
Refer to chapter
3.6.2.
☐
11
Double check every power cables, communication
cables installed well. And ADD Switches are setting right.
Refer to chapter
3.6.2 and 3.6.3.
☐
12
Check the UPS is turned on. And the UPS is power
supplying. (If configured)
Refer to chapter
3.6.4.
☐
13
Switch the external power or PCS on, to sure all the
power equipments can work normally.
Refer to chapter
3.6.4.
☐
14
Turn the BMS (Battery Control Modules) of each battery
string on (from 1
st
BMS to the last, one by one)
 Turn on the “Power Switch”:
 Turn on the “Start Button”:
 The battery string’s system will check itself, if
work normal the battery string system will goes
into self-check mode.
If has failure during the self-check, must debug
the failure then can start next step.
Refer to chapter
3.6.4.
