If every battery string are working normally.
Then switch the MBMS on. The MBMS will self-check and
check each battery string one by one.
Refer to chapter
3.6.4.
☐
16
The first installation should do full charging progress.
After MBMS has communicated with each BMS, it will run
parallel operation. It will begin from lowest voltage
battery string to do the parallel operation during the
charging.
If the status LED of BMS turns to green, it means this
battery string is in parallel operation.
The first
installation should
do full charging
progress.
Annex 3: System Turn OFF Progress List
Tick after
completion
No.
Item
Remark
☐
1
Soft-off the PCS through PCS’s control panel.
Refer to chapter
3.6.5.
☐
2
Turn off the switch between PCS and this battery string
(PowerCube-X1/X2), or turn off the power switch of PCS,
to make sure no current through this battery string.
Refer to chapter
3.6.5.
☐
3
Turn off all the “Power Switch” of the BMS.
Refer to chapter
3.6.5.
☐
4
Turn off the “Power Switch” of the MBMS.
Refer to chapter
3.6.5.
☐
5
Turn off the UPS. (If configured.)
 The UPS can turn on to check the equipment (PCS
or battery system etc.). Otherwise must turn off the
UPS to save its power.
Refer to chapter
3.6.5.
