66
PICTURE 5.3-3
PICTURE 5.3-4
TEST
You can see the status of your DVR’s connection
to remote cameras and save the results for
analysis. This is useful if you are experiencing
problems receiving video.
1. Enter the camera’s network address found in
the Camera > Remote Window (Picture 5.3-4)
(see Section 4.1) into the Destination IP field.
2. Click Test.
3. Messages regarding the test will appear below
the Destination IP field.
Advanced users can analyze the network
connection by saving the “network sniffer packet”
to a USB flash drive.
1. Connect a USB drive.
2. Navigate to the location where you want to save
the sniffer packet on the USB drive.
3. Click the yellow icon at the far right to start
recording the data.
4. Click the yellow icon again to end the recording.
•Packetleswillbesavedinthe.pcapformat.
