QSD2308L/QSD2316L DVR User’s Manual
19
3.3.4 Motion Detection Recording
This unit supports recording channels and PTZ linking. This means it will
record any cameras, or trigger any speed dome to preset or do auto cruise
once motion is detected on the camera’s channel.
STEP1 Enter MOTION configuration, see Fig 3.10 Motion Detection Setup.
Select cameras
Fig 3.10 Motion Detection Setup
STEP2 Enable Detection first. Enter Area to set Sensitivity and detection
Area. In detection area, red means not active, transparent means active, see
Fig 3.11 Motion Detection Area Setup.
Fig 3.11 Motion Detection Area Setup
STEP3 Enter Trigger configuration, see Fig 3.12 Alarm Out Setup
Fig 3.12 Alarm Out Setup
