Appendix D DVR Specifications (8 CH)
Compression format
Standard H.264 Baseline
Video output
Composite：1.0V p-p/75Ω，BNC×2
S-VIDEOX1, VGAX1
Video input
Composite：1.0V p-p/75Ω，BNC×8
Display Resolution
720*576 (PAL), 720*480 (NTSC)
Record Resolution
352*288 (PAL)
352*240 (NTSC)
Display Frame Rate
200FPS (PAL), 240FPS (NTSC)
Record Frame Rate
100FPS (PAL)
120FPS (NTSC)
Audio input
-8dB~ 22k, RCA X4
Audio output
-8Db~92dB, RCA X1
Alarm input
NO or NC 8CH
Alarm output:
4CH
Record Mode
Manual / Sensor /Timer / Motion
detection
Simplex/Duplex/Triplex
Pentaplex
Network Interface
RJ45 (LAN, INTERNET)
PTZ control
YES
Communication ports
RS485, USB2.0 x 2(one for backup,
another for USB mouse), PS/2 x 1
Drives supported
SATA x 2+DVD-RW x 1
Remote control
YES
Power supply
12V 6A
