qpcom QP-WR154N User Manual

www.qpcom.com/www.qpcom.com.co
PPPoE
This page is used to configure the parameters for Internet network witch connects to the
WAN port of your Access Point. Here you may change te access method to static IP,
DHCP, PPPoE, PPTP or L2TP by click the item value of WAN Access Type.
WAN Access Type:
User Name:
Password:
Service Name:
Connection Type:
Idle Time:
MTU Size:
Attain DNS Automatically
Set DNS Manually
DNS1:
DNS2:
DNS3:
Clone MAC Address:
Enable uPNP
Enable IGM Proxy
Enable Ping Access on WAN
Enable Web Server Access on WAN
Enable IPsec pass through on VPN connection
Enable PPT pass through on VPN connection
Enable L2TP pass through on VPN connection
WAN Interface Setup
PPPoE
Continuous
Apply Changes
Reset
Connect
Disconnect
00000000000
1492 (1400-1492 bytes)
1492 (1400-1492 bytes)
Item
Description
PPPoE Click to select PPPoE support on WAN interface.
There are user name, password, connection type and
idle time settings need to be done.
User Name
If you select the PPPoE support on WAN interface, fill
in the user name and password to login the PPPoE
server.
Password
If you select the PPPoE support on WAN interface, fill
in the user name and password to login the PPPoE
server.
Service Name
Fill in the service name of Service Name. The default
value is empty.
Connection Type
Select the connection type from pull-down menu.
There are Continuous, Connect on Demand and
Manual three types to select.
Continuous connection type means to setup the
connection through PPPoE protocol whenever this
WLAN AP Router is powered on.
Connect on Demand connection type means to setup
the connection through PPPoE protocol whenever you
send the data packets out through the WAN interface;
there are a watchdog implemented to close the PPP
oE
connection while there are no data sent out longer than
the idle time set.
Manual connection type means to setup the
connection through the PPPoE protocol by clicking the
Connect button manually, and clicking the Disconnect
button manually.
Idle Time If you select the PPPoE and Connect on Demand
connection type, fill in the idle time for auto-disconnect
function. Value can be between 1 and 1000 minutes.
MTU Size Fill in the mtu size of MTU Size. The default value is
1400.
Attain DNS
Automatically
Click to select getting DNS address for DHCP support.
Please select Set DNS Manually if the DHCP support
is selected.
Set DNS Manually Click to select getting DNS address for DHCP support.
DNS 1
Fill in the IP address of Domain Name Server 1.
DNS 2
Fill in the IP address of Domain Name Server 2.
DNS 3 Fill in the IP address of Domain Name Server 3.
Clone MAC Address Fill in the MAC address that is the MAC address to be
cloned.
Enable uPNP
Click the checkbox to enable uPNP function.
Enable IGMP Proxy
Click the checkbox to enable IGMP Proxy.
Enable Ping Access on
WAN
Click the checkbox to enable WAN ICMP response.
Enable Web Server
Access on WAN
Click the checkbox to enable web configuration from
WAN side.
Enable IPsec pass
through on VPN
connection
Click the checkbox to enable IPSec packet pass
through.
Enable PPTP pass
through on VPN
Click the checkbox to enable PPTP packet pass
through.
