28 QSC Audio Products, Inc.
TD-000083-00
IC-000134-00
Driver, MOSFET, IR2110; 14-pin DIP
1
2
3
4
5
6
7
14
13
12
11
10
9
8
HIN
V
DD
SD
LIN
V
SS
V
S
V
B
HO
V
CC
COM
LO
QD-000022-QD
Diode Zener, 18V, 1W, 1N4746A, DO-41
QD-000023-QD
Diode Zener, 180V, , 1.5W, 1N5955A, DO-41
QD-000047-00
Diode Zener, 200V, , 1.5W, 1N5956B, DO-41
QD-000080-20
Diode Zener, 11V, 1W, 1N4741A, DO-41
QD-000159-20
Diode Zener, 47V, 1W, 1N4756, DO-41
QD-000159-20
Diode Zener, 47V, , 1W, 1N4756, DO-41
AK
QD-000042-00
Diode rectifier ultrafast, 400V, 3A, MUR440, DO-201AD, 50 ns
AK
PD-000036-30
Power supply signal management, GAL16V8, PL9.0
PFC
and PL6.0
PFC
This device must be programmed by QSC before installation.
QD-000024-QD
Diode Zener, 6.2V, , 0.25W, DZ901116G, DO-35
AK
QD-000052-00
LED green, T-1, diffused
QD-000053-00
LED yellow, T-1
QD-000054-00
LED red, T-1
ANODE
CATHODE
232019
18
16
14
13119
8
6
4
I I I/CLK Vcc I/O/Q
I GND I/OE
I/O/Q I/O/Q
I/O/Q
I/O/Q
I/O/Q
I/O/Q
I/O/Q
I
I
I
I
I
