40 QSC Audio Products, Inc.
TD-000083-00
Chassis Assembly, Rear (QSC Part # WP-000172-00)
Where used: PL9.0
PFC
, 120 and 230 volts.
This is a subassembly of Chassis Assembly WP-000170-00 or WP-000170-02; one per amplifier.
QSC Part # Description Qty Comments
CO-000146-00 BINDING POST, SINGLE, 1 POS, FEMALE, 60A BLACK 2
CO-000147-00 BINDING POST, SINGLE, 1 POS, FEMALE, 60A RED 2
CH-000108-00 CHASSIS, REAR, , PL9.0, 1
LB-000216-00 WARNING, SHOCK CAUTION, , PL9.0, FCC CLASS A 1
LB-000218-00 PRODUCT, REAR, , PL9.0, 1
MS-000105-00 FAN, 24VDC, 3.62", ASSY, 4
NW-080002-00 FLAT WASHER, #8, , STAINLESS STEEL, BLACK 16
NW-500020-03 FLAT WASHER, 0.265", , , ZINC PLATED 8
PL-000045-PL RIVET, SCREW HEAD, 0.410" PANEL, PLASTIC, BLACK, 16
SC-030045-PB PHILLIPS, BINDERHEAD, #3-48, 0.25" L, BLACK, 4
SC-040041-PP PHILLIPS, PANHEAD, #4-40, 0.25" L, BLACK, 2
SC-060060-PS PHILLIPS, SEMS EXTERNAL TOOTH, #6-32, 0.375" L, ZINC, 2
WP-000175-00 PCB ASSY, INPUT, PL9.0, , 1
WP-000179-00 PCB ASSY, OUTPUT, PL9.0, , 1
Input PCB Assembly (QSC part # WP-000272-00)
Where used: PowerLight 6.0 II, 120 and 230 volts.
This is a subassembly of the Chassis Assembly, Rear (WP-000271-00); one per amplifier.
QSC Part # Description Qty Comments Reference
CA-122001-10 220PF, 10 PCNT, 100V, CERAMIC NPO, DISC, 4 C300, C302, C400, C402
CA-410004-10 0.1UF, 20 PCNT, 50V, CERAMIC Z5U, DIPPED, 4 C301, C303, C401, C403
CO-000168-00 XLR, COMBO, 3 POS, FEMALE, VERTICAL 2 J301, J401
IC-000072-OP OPAMP, DUAL, TL072, , 2 U300, U400
PC-000175-00 INPUT, PL9.0, , 1
QD-000062-10 TRANSISTOR NPN, 40V, 0.2A, 1.5W, 2N3904, TO-92, 1 Q1
QD-001340-LR LED RED, , , , , T-1 3/4, VOLTAGE REFERENCE 2 FLUSH TO THE PCB, CUT & CLINCH BOTH LEADS, AVOID TRACES LD1, LD2
QD-004148-DX DIODE, 75V, 0.075A, , 1N4148, DO-35, 4NS 2 D1, D2
RE-003305-BC 33, 5 PCNT, 1/4W, CARBON FILM, , 1 R10
RE-004751-BM 47.5, 1 PCNT, 1/4W, METAL FILM, , 3 R13, R306, R406
RE-110001-10 1.00K, 1 PCNT, 1/3W, METAL FILM, , 8 R300–R303, R400–R403
RE-134802-10 3.48K, 1 PCNT, 1/8W, METAL FILM, , 4 R1–R3, R22
RE-151100-10 5.11K, 1/4W, 1 PCNT, METAL FILM, , 1 R12
RE-190901-BM 9.09K, 1 PCNT, 1/4W, METAL FILM, , 5 R4, R304, R305, R404,
R405
RE-220001-10 20.0K, 1 PCNT, 1/3W, METAL FILM, , 2 R20, R23
SW-000043-00 SWITCH, 4P3T, SLIDE, PCB MOUNT 1 SW1
WC-000128-00 RIBBON CABLE ASSY, , 28 AWG, 16 CONDUCTOR, PL9.0, 8.75" L, 2
WP-000178-00 PCB ASSY, INPUT DAUGHTER, PL6.0/PL9.0, , 1
Output PCB Assembly (QSC part # WP-000179-00)
Where used: All models, 120 or 230 volts.
This is a subassembly of the Chassis Assembly, Rear (WP-000271-00, WP-000264-00, or WP-000172-00); one per amplifier.
QSC Part # Description Qty Comments
CA-410009-00 0.1UF, 5 PCNT, 250V, FILM, WRAPPED, 2 USE .050 SPACER
CO-000036-CO JACK, SPEAKON, 4 POS, FEMALE, 2
PC-000179-00 OUTPUT, PL9.0, , 1 APPLY MASKING DOTS 8 PLACES FOR BINDING POST, AND E1
