PowerLight 9.0
PFC
, PowerLight 6.0
PFC
, PowerLight 6.0 II Service Manual 37
Parts lists
PL-000137-00 INSULATOR, REAR BOTTOM, PL9.0, FISH PAPER, ,2
SC-040155-HC HEX, CAP, #4-40, 0.25" L, STAINLESS STEEL, SHOULDER 2
SC-060042-PP SC, PHILLIPS, PANHEAD SEMS INTERNAL TOOTH, #6-32, 0.25" L, BLK, ZINC, 13
SC-062120-PP PHILLIPS, PANHEAD, #6, 0.75" L, ZINC, TYPE B2
SC-080051-PS PHILLIPS, PANHEAD SEMS INTERNAL TOOTH, #8-32, 0.313" L, BLACK, 3
SC-080051-PU PHILLIPS, FLATHEAD UNDERCUT 100 DEGREE, #8-32, 0.313" L, BLACK, PATCH 10
SC-082051-PL PHILLIPS, PANHEAD SERATED BASE, #8, 0.313" L, BLACK, 21
SC-083061-PU PHILLIPS, FLATHEAD UNDERCUT, #8, 0.375" L, BLACK WAXED, TYPE B2
SC-100062-SC PHILLIPS, PANHEAD, #10-32, 0.375" L, NICKEL, 4
SW-000027-SW AC SWITCH, DPST, 22A, 125VAC, 1
WC-000022-00 AC CORD, IEC, 16 AWG, 3 CONDUCTOR, , 2.5 METERS, 250 VAC 1
WC-000123-00 WIRE ASSY, OUTPUT, 10 AWG, 1 CONDUCTOR, PL9.0, 15" L, BLACK 1
WC-000123-01 WIRE ASSY, OUTPUT, 10 AWG, 1 CONDUCTOR, PL9.0, 20" L, BLACK 1
WC-000124-00 WIRE ASSY, OUTPUT, 10 AWG, 1 CONDUCTOR, PL9.0, 15" L, WHITE 1
WC-000124-01 WIRE ASSY, OUTPUT, 10 AWG, 1 CONDUCTOR, PL9.0, 20" L, WHITE 1
WC-000135-00 CABLE ASSY, IEC/AC FILTER, 12 AWG, 3 CONDUCTOR, PL9.0, 5" L, 1
WP-000176-00 PCB ASSY, DISPLAY, PL9.0, ,1
WP-000181-00 PCB ASSY, LINE FILTER, PL9.0, 230V, 1
WP-000262-02 PCB ASSY, POWER SUPPLY, PL6.0, 230V, 2
WP-000264-00 CHASSIS ASSY, REAR, PL6.0, ,1
WP-000276-00 PCB ASSY, , PL 6.0 (NEW), ,2
Chassis Assembly WP-000260-02 (continued)
QSC Part # Description Qty Comments Ref erence
Chassis Assembly (QSC part # WP-000170-00)
Where used: PowerLight 9.0
PFC
, 120 volts
QSC Part # Description Qty Comments
CH-000078-00 CHASSIS, MAIN, , PL9.0, 1
CH-000080-00 PAN, MAIN, , PL9.0, 1
CH-000084-00 PARTITION, LINE FILTER, , PL9.0, 1
CH-000086-00 RACK EAR, REAR, , PL9.0, 2
CH-000087-00 RACK EAR, FRONT, , PL9.0, 2
HW-060006-SO STANDOFF, 0.250" HEX, #6-32, 1.186" L, ALUMINUM, MALE/FEMALE 4
HW-060080-HW STANDOFF, 0.250" HEX, #6-32, 0.500" L, ALUMINUM, MALE/FEMALE 3
HW-060090-SO STANDOFF, 0.250" HEX, #6-32, 0.563" L, ALUMINUM, FEMALE 5
LB-000052-00 AGENCY, LISTING, , , UL/CUL 1
LB-000217-00 PRODUCT, FACEPLATE, , PL9.0, 1
NW-000021-03 FLAT WASHER, 1.14", , ALUMINUM, BLACK ANODIZED 1
NW-080001-NW LOCK WASHER, #8, EXTERNAL TOOTH, , ZINC PLATE 1
NW-080500-KP KEPS NUT, #8-32, , , 7
NW-100710-NW LOCK WASHER, #10, EXTERNAL TOOTH, , NICKEL PLATED 4
NW-250705-04 HEX NUT, 1/4"-28, 7/16", STAINLESS STEEL, 4
PL-000000-AF BUMPER, ADHESIVE BACKED, 0.812" X 0.812", POLYURETHANE, BLACK, 2
PL-000054-00 KNOB, , PLX, POLYPROPYLENE/SANTOPRENE, BLACK, 2
PL-000101-00 INSULATOR, POWER SUPPLY, PL9.0, FISH PAPER, , 1
PL-000102-00 INSULATOR, AC LINE FILTER LEFT, PL9.0, FISH PAPER, , 1
PL-000103-00 INSULATOR, AC LINE FILTER RIGHT, PL9.0, FISH PAPER, , 1
PL-000104-00 INSULATOR, HIGH VOLTAGE, PL9.0, FISH PAPER, , 1
PL-000106-00 INSULATOR, HEAT SINK RIGHT, PL9.0, FISH PAPER, , 2
PL-000107-00 INSULATOR, POWER SUPPLY UPPER, PL9.0, FISH PAPER, , 2
PL-000108-00 INSULATOR, HEAT SINK LEFT, PL9.0, FISH PAPER, , 2
PL-000109-00 INSULATOR, HEAT SINK CENTER, PL9.0, FISH PAPER, , 2
PL-000124-00 INSULATOR, POWER SUPPLY LOWER FRONT, PL9.0, FISH PAPER, , 1
PL-000125-00 INSULATOR, POWER SUPPLY LOWER REAR, PL9.0, FISH PAPER, , 1
PL-000130-00 INSULATOR, PARTITION LOWER FRONT LEFT, PL9.0, FISH PAPER, , 1
PL-000130-01 INSULATOR, PARTITION LOWER FRONT RIGHT, PL9.0, FISH PAPER, , 1
PL-000131-00 INSULATOR, PARTITION LOWER REAR, PL9.0, FISH PAPER, , 2
PL-000137-00 INSULATOR, REAR BOTTOM, PL9.0, FISH PAPER, , 2
SC-040155-HC HEX, CAP, #4-40, 0.25" L, STAINLESS STEEL, SHOULDER 2
SC-060042-PP SC, PHILLIPS, PANHEAD SEMS INTERNAL TOOTH, #6-32, 0.25" L, BLK, ZINC, 13
SC-060060-PS PHILLIPS, SEMS EXTERNAL TOOTH, #6-32, 0.375" L, ZINC, 4
SC-062120-PP PHILLIPS, PANHEAD, #6, 0.75" L, ZINC, TYPE B 2
