PowerLight 9.0
PFC
, PowerLight 6.0
PFC
, PowerLight 6.0 II Service Manual 63
Parts lists
WC-000133-00 JUMPER, TEFLON INSULATION, 16 AWG SOLID, 1 CONDUCTOR, , 1.75" L, 2 T2,3
WC-000137-00 JUMPER, PVC INSULATION, 14 AWG, 1 CONDUCTOR, , 1.3" L, 3 W11–W13
WC-2.5218-JW JUMPER, TEFLON INSULATION, 18 AWG, 1 CONDUCTOR, , 2.5" L, 0.250" LEAD LENGTH 1 W8
WP-000056-00 FET ASSY, MATCHED, PL6.0/PL9.0, , 1 Q1-4 USE THE SCREWS IN THE PACKAGE TO ASSEMBLE THE HEATSINK TO PCB
WP-000174-00 PCB ASSY, PS CONTROLLER, PL9.0, , 1
XF-000039-00 TRANSFORMER, SWITCHING, 100KHZ, , 4000W, PL9.0, , 1 T1
XF-000042-00 INDUCTOR, COMMON MODE, TOROID, , PL9.0, , 1 L2
XF-000047-00 INDUCTOR, POWER, , 45UH, PL9.0, 240V, 1 L1
XF-000077-00 INDUCTOR, CURRENT SENSE, TOROID, 100TURN, PL9.0, , 2 CUT AND REMOVE GRAY WIRES T2, T3
Power Supply Controller Assembly (QSC part # WP-000174-00)
Where used: PowerLight 9.0
PFC
, 120 and 230 volts.
This is a subassembly of the Power Supply Assembly, WP-000173-00 or WP-000180-00; two per amplifier.
QSC Part # Description Qty Comments Reference
CA-110002-30 100PF, 5 PCNT, 50V, CERAMIC NPO, 0805, 1 C33
CA-122002-30 220PF, 5 PCNT, 50V, CERAMIC NPO, 0805, 1 C26
CA-147004-30 470PF, 5 PCNT, 50V, CERAMIC NPO, 0805, 2 C43, C73
CA-210006-30 0.001UF, 2 PCNT, 100V, CERAMIC NPO, 0805, 4 C3, C35–C37
CA-222050-CP 0.0022UF, 5 PCNT, 50V, FILM, DIPPED, NON-AI 1 USE .050 SPACER C41
CA-310001-10 0.01UF, 10 PCNT, 100V, FILM, DIPPED, 1 C42
CA-347002-30 0.047UF, 20 PCNT, 50V, CERAMIC Z5U, 0805, 58 C2, C5, C6, C11, C13,
C18–C23, C25, C27–C29,
C31, C32, C38, C44, C46,
C48, C50–C54, C56–C63,
C67–C69, C72, C77, C79,
C81–C92
CA-347004-30 0.047UF, 20 PCNT, 50V, CERAMIC X7R, 1206, 1 C65
CA-410002-10 0.1UF, 5 PCNT, 100V, FILM, DIPPED, 1 C47
CA-410006-30 0.1UF, 10 PCNT, 50V, CERAMIC X7R, 1206, 2 C7, C8
CA-510001-10 1.0UF, 20 PCNT, 50V, CERAMIC Z5U, DIPPED, 3 C30, C34, C49
CA-610006-30 10UF, 20 PCNT, 16V, ELECTROLYTIC, SMT, 7 C4, C14, C40, C45, C70,
C71, C93
CA-622002-30 22UF, 20 PCNT, 25V, TANTALUM, SMT, 5 C9, C10, C15–C17
CA-633001-00 33UF, 20 PCNT, 400V, ELECTROLYTIC, , 1 USE .050 SPACER C12
CO-000074-00 HEADER, 0.1" CENTERS, 8 POS (1X8), MALE, RAMP LOCK 2 REF: J100,101
CO-000157-00 HEADER, 0.1" CENTERS, 8 POS (1X8), MALE, RIGHT ANGLE 2 J102, J103
CO-000158-00 HEADER, 0.1" CENTERS, 4 POS (1X4), MALE, RIGHT ANGLE 2 J104, J105
IC-000031-00 OPTO ISOLATOR, , 4N30, , 1 U22
IC-000042-00 VOLTAGE REGULATOR, +5V, MC7805CT, , 1 U9
IC-000049-00 OPTO COUPLER, , HCPL2200, , 2 U14, U13
IC-000050-00 OPTO COUPLER, , 6N137, , 1 U1
IC-000051-00 OPTO ISOLATOR, , MOC8101, , 1 U5
IC-000053-30 TIMER, DUAL, LM556, , 1U2
IC-000054-30 COMPARATOR, QUAD, LM339AM, SMT, 3 U16, U19, U21
IC-000055-30 REGULATOR, POWER FACTOR, UC3854B, , 1 U18
IC-000056-30 DRIVER, MOSFET, TC4427, SMT, 1 U11
IC-000057-30 COUNTER, RIPPLE, 74HC4024, SMT, 1 U12
IC-000059-00 TOP SWITCH, , TOP202, , 1 U7
IC-000060-00 OSCILLATOR, CLOCK, 6.000 MHZ, , 1 U10
IC-000063-30 OPAMP, QUAD, MC33074, , 2 U17, U20
IC-000085-00 VOLTAGE REGULATOR, +12V, LM2937ET-12, , LOW DROP OUT 2 U4, U8
PC-000174-00 POWER SUPPLY CONTROLLER, PL9.0, , 1
PD-000036-30 POWER SUPPLY SIGNAL MANAGEMENT, GAL16V8, PL9.0, , 1 U15
PT-210000-AT TRIM, 1K, 20 PCNT, 0.15W, , 1 VR4
PT-220000-AT TRIM, 2K, 20 PCNT, 0.15W, , 1 VR1
PT-250000-AT TRIM, 5K, 20 PCNT, 0.15W, , 1 VR3
PT-410000-AT TRIM, 100K, 20 PCNT, 0.15W, , 1 VR2
QD-000102-30 DIODE, 75V, 0.075A, , IMBD4148, SOT-23, 4NS 5 D1, D11, D13, D15, D6
Power Supply Assembly WP-000180-02 (continued)
QSC Part # Description Qty Comments Ref erence
