PowerLight 9.0
PFC
, PowerLight 6.0
PFC
, PowerLight 6.0 II Service Manual 39
Parts lists
SC-082051-PL PHILLIPS, PANHEAD SERATED BASE, #8, 0.313" L, BLACK, 21
SC-083061-PU PHILLIPS, FLATHEAD UNDERCUT, #8, 0.375" L, BLACK WAXED, TYPE B 2
SC-100062-SC PHILLIPS, PANHEAD, #10-32, 0.375" L, NICKEL, 4
SW-000027-SW AC SWITCH, DPST, 22A, 125VAC, 1
WC-000022-00 AC CORD, IEC, 16 AWG, 3 CONDUCTOR, , 2.5 METERS, 250 VAC 1
WC-000123-00 WIRE ASSY, OUTPUT, 10 AWG, 1 CONDUCTOR, PL9.0, 15" L, BLACK 1
WC-000123-01 WIRE ASSY, OUTPUT, 10 AWG, 1 CONDUCTOR, PL9.0, 20" L, BLACK 1
WC-000124-00 WIRE ASSY, OUTPUT, 10 AWG, 1 CONDUCTOR, PL9.0, 15" L, WHITE 1
WC-000124-01 WIRE ASSY, OUTPUT, 10 AWG, 1 CONDUCTOR, PL9.0, 20" L, WHITE 1
WC-000135-00 CABLE ASSY, IEC/AC FILTER, 12 AWG, 3 CONDUCTOR, PL9.0, 5" L, 1
WP-000172-00 CHASSIS ASSY, REAR, PL9.0, , 1
WP-000176-00 PCB ASSY, DISPLAY, PL9.0, , 1
WP-000180-00 PCB ASSY, POWER SUPPLY, PL9.0, 230V, 2
WP-000181-00 PCB ASSY, LINE FILTER, PL9.0, 230V, 1
WP-000182-00 PCB ASSY, , PL 9.0 (NEW), , 2
Chassis Assembly WP-000170-02 (continued)
QSC Part # Description Qty Comments Ref erence
Chassis Assembly, Rear (QSC part # WP-000271-00)
Where used: PowerLight 6.0 II, 120 and 230 volts
This is a subassembly of Chassis Assembly WP-000268-00 or WP-000268-02; one per amplifier.
QSC Part # Description Qty Comments
CH-000108-00 CHASSIS, REAR, , PL9.0, 1
CO-000146-00 BINDING POST, SINGLE, 1 POS, FEMALE, 60A BLACK 2
CO-000147-00 BINDING POST, SINGLE, 1 POS, FEMALE, 60A RED 2
LB-000216-00 WARNING, SHOCK CAUTION, , PL9.0, FCC CLASS A 1
LB-000218-00 PRODUCT, REAR, , PL9.0, 1
MS-000105-00 FAN, 24VDC, 3.62", ASSY, 4
NW-080002-00 FLAT WASHER, #8, , STAINLESS STEEL, BLACK 16
NW-500020-03 FLAT WASHER, 0.265", , , ZINC PLATED 8
PL-000045-PL RIVET, SCREW HEAD, 0.410" PANEL, PLASTIC, BLACK, 16
SC-030045-PB PHILLIPS, BINDERHEAD, #3-48, 0.25" L, BLACK, 4
SC-040041-PP PHILLIPS, PANHEAD, #4-40, 0.25" L, BLACK, 2
SC-060060-PS PHILLIPS, SEMS EXTERNAL TOOTH, #6-32, 0.375" L, ZINC, 2
WP-000179-00 PCB ASSY, OUTPUT, PL9.0, , 1
WP-000272-00 PCB ASSY, INPUT, PL6.0II, , 1
Chassis Assembly, Rear (QSC part # WP-000264-00)
Where used: PowerLight 6.0
PFC
, 120 and 230 volts
This is a subassembly of Chassis Assembly WP-000260-00 or WP-000260-02; one per amplifier.
QSC Part # Description Qty Comments
CH-000108-00 CHASSIS, REAR, , PL9.0, 1
CO-000146-00 BINDING POST, SINGLE, 1 POS, FEMALE, 60A BLACK 2
CO-000147-00 BINDING POST, SINGLE, 1 POS, FEMALE, 60A RED 2
LB-000216-00 WARNING, SHOCK CAUTION, , PL9.0, FCC CLASS A 1
LB-000218-00 PRODUCT, REAR, , PL9.0, 1
MS-000105-00 FAN, 24VDC, 3.62", ASSY, 4
NW-080002-00 FLAT WASHER, #8, , STAINLESS STEEL, BLACK 16
NW-500020-03 FLAT WASHER, 0.265", , , ZINC PLATED 8
PL-000045-PL RIVET, SCREW HEAD, 0.410" PANEL, PLASTIC, BLACK, 16
SC-030045-PB PHILLIPS, BINDERHEAD, #3-48, 0.25" L, BLACK, 4
SC-040041-PP PHILLIPS, PANHEAD, #4-40, 0.25" L, BLACK, 2
SC-060060-PS PHILLIPS, SEMS EXTERNAL TOOTH, #6-32, 0.375" L, ZINC, 2
WP-000179-00 PCB ASSY, OUTPUT, PL9.0, , 1
WP-000265-00 PCB ASSY, INPUT, PL6.0, , 1
