60 QSC Audio Products, Inc.
TD-000083-00
Power Supply Assembly (QSC part # WP-000173-00)
Where used: PowerLight 9.0
PFC
, 120 volts.
This is a subassembly of the Chassis Assembly, WP-000170-00; two per amplifier.
QSC Part # Description Qty Comments Reference
CA-147100-BD 470PF, 10 PCNT, 100V, CERAMIC Y5F, DISC, 4 C1–C4
CA-210007-00 0.001UF, 5 PCNT, 500V, MICA, DIPPED, 4 C27, C29, C33, C35
CA-222004-00 0.0022UF, 5 PCNT, 500V, MICA, DIPPED, 2 C40, C41
CA-247001-00 0.0047UF, 5 PCNT, 500V, MICA, DIPPED, 2 C44, C45
CA-310001-10 0.01UF, 10 PCNT, 100V, FILM, DIPPED, 1 C7
CA-347400-BP 0.047UF, 10 PCNT, 400V, FILM, DIPPED, 4 C13,18 NEED TO BE LAID FLAT ON THE PCB C13, C18, C23, C37
CA-410009-00 0.1UF, 5 PCNT, 250V, FILM, WRAPPED, 1 PREP AT VERTICAL POSITION /USE .050 SPACER C20
CA-422001-10 0.22UF, 5 PCNT, 50V, FILM, DIPPED, LOW PROFILE 4 C47–C50
CA-510001-10 1.0UF, 20 PCNT, 50V, CERAMIC Z5U, DIPPED, 4 C5, C9, C14, C16
CA-550001-00 5.0UF, 10 PCNT, 250V, FILM, WRAPPED, HIGH FREQ LOW ESR 2 USE .1000 SPACER C43, C46
CA-568001-00 6.8UF, 10 PCNT, 400V, FILM, WRAPPED, 4 USE .1000 SPACER (PREP AT VERTICAL POSITION) C22, C24,
C31, C21
CA-610004-00 10UF, 20 PCNT, 25V, ELECTROLYTIC, , LOW PROFILE 2 C6, C10
CA-922002-00 22000UF, 20 PCNT, 50V, ELECTROLYTIC, , 8 C26, C28, C30, C32, C34,
C36, C42, C39
CH-000076-00 HEAT SINK, PS, FET, PL9.0, 1
CH-000077-00 HEAT SINK, DIODE, , PL9.0, 1
CH-000089-00 CLAMP, DIODE, 1 FINGER, PL9.0, 12
CO-000074-00 HEADER, 0.1" CENTERS, 8 POS (1X8), MALE, RAMP LOCK 1 J202
CO-000122-00 HEADER, 0.1" CENTERS, 8 POS (1X8), MALE, RIGHT ANGLE RAMP LOCK 1 J200
HW-000007-HW FUSE CLIP, PC MOUNT, , , TIN PLATED BRASS, 5MM 2 F1
HW-080006-SO SPACER, 0.312" ROUND, #8, 0.470" L, ALUMINUM, SWAGE 2 APPLY THE SWAGE TOOL, INSTALL ON TOP SIDE
HW-080080-PS STUD, PEM STYLE, #8-32, 0.500" L, TIN PLATED BRONZE, 2 E2,E3
IC-000064-00 DRIVER, MOSFET, 4452BN, , 2 U1, U3
MS-000113-00 FUSE, 1A, 250V, 5MM X 20MM, SLO-BLO 1 F1
NW-060000-PI PRESS-IN NUT, #6-32, PCB MOUNT, CARBON STEEL, 2 PL-000087-00, INSTALL ON BOTTOM SIDE
NW-062010-FW FLAT WASHER, #6, , , ZINC PLATE 2
NW-180001-03 FLAT WASHER, 0.177", , STAINLESS STEEL, 12
PC-000173-00 POWER SUPPLY, PL9.0, , 1
PL-000010-00 BUMPER, ADHESIVE BACKED, 0.5" X 0.5", POLYURETHANE, BLACK, 3
PL-000059-00 INSULATOR, TRANSISTOR, 1.125" X 2", MICA, , 2 D1,2,D7,8
PL-000085-00 INSULATOR, TRANSISTOR, 1.525" X 0.950", ALUMINA, , 5
PL-000086-00 INSULATOR, TRANSISTOR, 2.875" X 0.950", ALUMINA, , 1
PL-000087-00 CARD GUIDE, 0.063" PCB, 2.0" HEIGHT, , , VERTICAL 2 WP-000174-00, MATCH THE LOCATION ON THE SILK SCREEN
PL-000089-00 INSULATOR, RECTIFIER HEAT SINK, PL9.0, FISH PAPER, , 1
PL-000090-00 INSULATOR, TRANSFORMER/INDUCTOR, PL9.0, FISH PAPER, , 2
PL-000134-00 GROMMET, VIBRATION DAMPING, 0.375" OD, NEOPRENE, , 1
PL-000139-00 INSULATOR, POWER SUPPLY HEAT SINK, PL9.0, , , 1
PL-903125-SP SPACER, ROUND, 0.047"ID X 0.156"OD X 0.125"L, NYLON, , 2 W8
QD-000022-QD DIODE ZENER, 18V, , 1W, 1N4746A, DO-41, 4 D3–D6
QD-000023-QD DIODE ZENER, 180V, , 1.5W, 1N5955A, DO-41, 8 D30–D37
QD-000065-10 TRANSISTOR PNP, 300V, 0.5A, 1.5W, MPSA92, TO-92, 1 Q6
QD-000117-00 DIODE RECTIFIER FAST, 600V, 60A, , DSEI60-06A, TO-247AD, 35NS 2 D19, D20
QD-000118-00 BRIDGE RECTIFIER, 1000V, 1A, , , DIP, 1 BR1
QD-000120-20 DIODE RECTIFIER ULTRAFAST, 200V, 1A, , MUR120RL, DO-41, 35NS 3 D9–D11
QD-000125-00 DIODE RECTIFIER FAST, 600V, 37A, , DSEI30-06A, TO-247AD, 50NS 2 D21, D22
QD-000126-00 DIODE RECTIFIER FAST, 600V, 75A, , DSEI120-06A, TO-247AD, 50NS 4 D12, D14, D16, D17
QD-000164-10 TRANSISTOR NPN, 200V, 0.5A, 0.625W, MPSA43, TO-92, 1 Q5
QD-000183-00 DIODE, 600V, 60A, , 60EPS08, TO-247AD, PL9.0 4 D1, D2, D7, D8
QD-004004-DX DIODE, 400V, 1A, , 1N4004, DO-41, 2US 1 D18
QD-004148-DX DIODE, 75V, 0.075A, , 1N4148, DO-35, 4NS 2 D23, D24
QD-004753-ZT DIODE ZENER, 36V, , 1W, 1N4753A, DO-41, 2 D13, D15
RE-.24001-00 2.4, 5 PCNT, 5W, METAL OXIDE FP, , NON-INDUCTIVE 1 USE .050 SPACER R15
RE-.47501-10 4.75, 1 PCNT, 1/4W, METAL FILM, , 4 R5–R8
RE-001003-00 10, 10 PCNT, 5W, WIRE WOUND, VERTICAL, NON-INDUCTIVE 8 R16, R18, R22, R29, R30,
R32–R34
RE-003305-DM 33, 5 PCNT, 1W, METAL OXIDE FP, , 2 R13, R14
RE-010003-10 100, 1 PCNT, 1/8W, METAL FILM, , 1 R17
RE-110001-AM 1.00K, 1 PCNT, 1/8W, METAL FILM, , 2 R1, R2
RE-147005-DM 4.7K, 5 PCNT, 1W, METAL OXIDE FP, , 4 R35–R38
