PowerLight 9.0
PFC
, PowerLight 6.0
PFC
, PowerLight 6.0 II Service Manual 59
Parts lists
QD-000102-30 DIODE, 75V, 0.075A, , IMBD4148, SOT-23, 4NS 5 D1, D6, D11, D13, D15
QD-000103-30 TRANSISTOR NPN, 40V, 0.2A, 0.2W, MMST3904, SOT-23, 7 Q3–Q5, Q7–Q10
QD-000104-30 TRANSISTOR PNP, 40V, 0.2A, 0.2W, MMST3906, SOT-23, 3 Q2, Q12, Q14
QD-000114-30 DIODE ZENER, 150V, , 600W PEAK, P6SMB150AT3, SMB, 1 D3
QD-000115-30 DIODE RECTIFIER ULTRAFAST, 600V, 1A, , MURS160T3, SMB, 75NS 2 D4, D5
QD-000116-30 DIODE RECTIFIER ULTRAFAST, 200V, 1A, , MURS120, SMB, 35NS 4 D2, D8–D10
QD-000136-30 DIODE ZENER, 7.5V, , 0.3W, BZX84C7V5, SOT-23, 1 D7
QD-000163-30 LED RED, , , , , SML-010, VOLTAGE REFERENCE 1 LD1
QD-000168-30 DIODE SCHOTTKY, 70V, 0.2A, , BAS70-04, SOT-23, 2 D12, D14
RE-007502-30 75, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R72
RE-018201-30 182, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R15
RE-020002-30 200, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R2
RE-033205-30 332, 0.1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R18
RE-090901-30 909, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R37
RE-110002-30 1.00K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 15 R4, R19, R20, R24, R25,
R35, R43, R46, R47, R51,
R54, R75, R80, R84, R98
RE-110502-30 1.05K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R22, R86
RE-115002-30 1.50K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 4 R7, R16, R17, R70
RE-120002-30 2.00K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R48
RE-124902-30 2.49K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R50, R97
RE-130102-30 3.01K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R13, R14
RE-134802-30 3.48K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R68
RE-147502-30 4.75K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 8 R23, R32–R34, R38, R60,
R90, R92
RE-152301-30 5.23K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R29
RE-160401-30 6.04K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 4 R36, R44, R45, R79
RE-163402-30 6.34K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R58
RE-175002-30 7.50K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R5
RE-178702-30 7.87K, 0.1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R57, R83
RE-210003-30 10.0K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 9 R21, R31, R39, R73, R91,
R93–R96
RE-212702-30 12.7K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 3 R41, R52, R78
RE-215002-30 15.0K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 4 R82, R85, R87, R101
RE-221502-30 21.5K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 7 R10, R56, R59, R65, R71,
R74, R81
RE-224901-30 24.9K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R9, R11
RE-227401-30 27.4K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R28
RE-239203-30 39.2K, 0.1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R55
RE-245302-30 45.3K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R3
RE-247503-30 47.5K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R69, R77
RE-310002-30 100K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 9 R6, R8, R26, R27, R30,
R66, R67, R76, R88
RE-314001-30 140K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R12
RE-375001-30 750K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R40
XF-000037-00 TRANSFORMER, HOUSEKEEPING, , , , PL9.0, , POWER SUPPLY 1 T1
Power Supply Controller Assembly WP-000263-00 (continued)
QSC Part # Description Qty Comments Ref erence
