52 QSC Audio Products, Inc.
TD-000083-00
RE-068001-10 680, 5 PCNT, 2W, METAL OXIDE FP, MINI, 1 R175
RE-090901-30 909, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R26
RE-093101-30 931, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R380
RE-113302-30 1.33K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R22
RE-120002-30 2.00K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R6
RE-122103-30 2.21K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 3 R18, R357, R367
RE-126700-30 2.67K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R337
RE-128702-30 2.87K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R1, R3
RE-147502-30 4.75K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 3 R12, R330, R339
RE-156202-30 5.62K, 0.1 PCNT, 1/10W, THICK FILM, 0805, 100V 3 R8, R13, R14
RE-163401-10 6.34K, 1 PCNT, 1/8W, METAL FILM, , 1 R4
RE-178702-30 7.87K, 0.1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R20
RE-197602-30 9.76K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R338
RE-210003-30 10.0K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 12 R5, R9–R11, R17, R19,
R24, R25, R63, R64,
R336, R363
RE-212104-30 12.1K, 0.1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R15
RE-212702-30 12.7K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R329
RE-215002-30 15.0K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R48, R366
RE-229402-30 29.4K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R29, R331
RE-230002-10 30K, 5 PCNT, 2W, METAL OXIDE FP, MINI, 1 R351
RE-230002-10 30K, 5 PCNT, 2W, METAL OXIDE FP, MINI, 5 R352–R356
RE-231601-30 31.6K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R325
RE-239202-30 39.2K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R332
RE-247503-30 47.5K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R323
RE-249900-30 49.9K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 5 R7, R34, R49, R50, R66
RE-263401-30 63.4K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R52, R53
RE-310002-30 100K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R56, R55
RE-315002-30 150K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V 2 R341, R342
RE-339202-30 392K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V 1 R340
RE-348702-30 487K, 1 PCNT, 1/8W, THICK FILM, 1206, 200V 4 R321, R322, R326, R328
SC-063100-PP PHILLIPS, PANHEAD, #6, 0.625" L, ZINC, TYPE AB 10
SW-000058-00 RELAY, SPDT, 12VDC COIL, 15A, 240VAC, 1 K1
WC-0.4016-JW JUMPER, 0.3" TEFLON INSULATION, 16 AWG, 1 CONDUCTOR, , 0.4", 2 W9, W10
WC-000125-00 CABLE ASSY, DC OUTPUT, 10 AWG, 5 CONDUCTOR, PL9.0, 6" L, 1 REF: E4-E8(0-E8,1-E7,2-E6,3-E5,4-E4) FOLK TERMINAL FACE-UP
WC-000237-00 RIBBON CABLE, FLEX STRIP, 24 AWG, 12 CONDUCTOR, PL6.0II, 11.25" L, 1 USE SPACER BETWEEN XF-000208-00 AND CABLE
WC-5.2514-00 JUMPER, PVC INSULATION, 14 AWG, 1 CONDUCTOR, EVICTOR, 5.25" L, 1
XF-000005-00 BEAD, 100MHZ, 271 OHM, 7 L7–L13
XF-000194-00 TRANSFORMER, SWITCHING, , , , NEW PL6.0, , 1 T3
XF-000204-00 HOUSEKEEPING, FLYBACK, , , , EVICTOR, , 1 T2
XF-000206-00 INDUCTOR, COMMON MODE, TOROID, 81UH, EVICTOR, , 1 L4
XF-000208-00 INDUCTOR, SERIES RESONANT, TOROID, 1.0UH, , , 1 L6
Power Supply Assembly (QSC part # WP-000266-02)
Where used: PowerLight 6.0 II, 230 volts.
This is a subassembly of the Chassis Assembly, WP-000268-02; two per amplifier.
QSC Part # Description Qty Comments Reference
CA-068002-30 68PF, 5 PCNT, 50V, CERAMIC NPO, 0805, 1 C40
CA-110001-10 100PF, 5 PCNT, 500V, MICA, DIPPED, 1 C147
CA-110002-30 100PF, 5 PCNT, 50V, CERAMIC NPO, 0805, 3 C1, C30, C39
CA-133001-10 330PF, 5 PCNT, 500V, MICA, DIPPED, 2 C145, C146
CA-147003-30 470PF, 5 PCNT, 50V, CERAMIC NPO, 1206, 2 C119, C121
CA-147004-30 470PF, 5 PCNT, 50V, CERAMIC NPO, 0805, 1 C22
CA-210006-30 0.001UF, 2 PCNT, 100V, CERAMIC NPO, 0805, 2 C2, C5
CA-215003-30 0.0015UF, 10 PCNT, 25V, CERAMIC X7R, 0805, 3 C44, C120, C124
CA-222001-00 0.0022UF, 20 PCNT, 125VAC, CERAMIC Y5U, DISC, YCAP 1 C122
CA-227001-30 0.0027UF, 10 PCNT, 100V, CERAMIC X7R, 0805, 3 C108, C109, C128
CA-233001-10 0.0033UF, 10 PCNT, 100V, FILM, DIPPED, 1 C113
Power Supply Assembly WP-000266-00 (continued)
QSC Part # Description Qty Comments Ref erence
