QSC PowerLight Series - Parts Lists; Chassis Assembly (QSC Part #WP-000268-00)

PowerLight 9.0
PFC
, PowerLight 6.0
PFC
, PowerLight 6.0 II Service Manual 33
Parts lists
4.2 Parts lists
Because of the complexity of these amplifiers, many repairs will involve simply replacing defective modules with good ones. The table
below lists the modules and major assemblies used in all three models for both 120- and 230-volt operation.
Assembly
PL 6.0 II PL 6.0
PFC
PL 9.0
PFC
120V 230V 120V 230V 120V 230V
Chassis assembly
WP-000268-00 WP-000268-02 WP-000260-00 WP-000260-02 WP-000170-00 WP-000170-02
▲ Chassis assembly, rear
WP-000271-00 WP-000264-00 WP-000172-00
▲▲ Output PCB assembly
WP-000179-00 WP-000179-00 WP-000179-00
▲▲ Input PCB assembly
WP-000272-00 WP-000265-00 WP-000175-00
▲▲▲ Input daughterboard
WP-000178-00 WP-000178-00
▲ Audio channel module
WP-000276-00 WP-000276-00 WP-000182-00
▲ Power supply assembly
WP-000266-00 WP-000266-02 WP-000262-00 WP-000262-02 WP-000173-00 WP-000180-00
▲▲ Power supply controller
WP-000263-00 WP-000174-00
▲ Display board assembly
WP-000176-00 WP-000176-00 WP-000176-00
▲ Line filter assembly
WP-000177-00 WP-000181-00 WP-000177-00 WP-000181-00 WP-000177-00 WP-000181-00
▲ Power cord assembly
WP-000042-00 WP-000022-00 WP-000042-00 WP-000135-00 WP-000042-00 WP-000135-00
For individual replacement parts, the lists on this and the following pages are organized by module or major assembly.
Chassis Assembly (QSC part #WP-000268-00)
Where used: PowerLight 6.0 II, 120 volts
QSC Part # Description Qty Comments
CH-000078-00 CHASSIS, MAIN, , PL9.0, 1
CH-000080-00 PAN, MAIN, , PL9.0, 1
CH-000084-00 PARTITION, LINE FILTER, , PL9.0, 1
CH-000086-00 RACK EAR, REAR, , PL9.0, 2
CH-000087-00 RACK EAR, FRONT, , PL9.0, 2
HW-060006-SO STANDOFF, 0.250" HEX, #6-32, 1.186" L, ALUMINUM, MALE/FEMALE 4
HW-060080-HW STANDOFF, 0.250" HEX, #6-32, 0.500" L, ALUMINUM, MALE/FEMALE 3
HW-060090-SO STANDOFF, 0.250" HEX, #6-32, 0.563" L, ALUMINUM, FEMALE 5
LB-000052-00 AGENCY, LISTING, , , UL/CUL 1
LB-000391-00 PRODUCT, FACEPLATE, , PL6.0II, 1
NW-000021-03 FLAT WASHER, 1.14", , ALUMINUM, BLACK ANODIZED 1
NW-080001-NW LOCK WASHER, #8, EXTERNAL TOOTH, , ZINC PLATE 1
NW-080500-KP KEPS NUT, #8-32, , , 7
NW-100710-NW LOCK WASHER, #10, EXTERNAL TOOTH, , NICKEL PLATED 4
NW-250705-04 HEX NUT, 1/4"-28, 7/16", STAINLESS STEEL, 4
PL-000000-AF BUMPER, ADHESIVE BACKED, 0.812" X 0.812", POLYURETHANE, BLACK, 2
PL-000054-00 KNOB, , PLX, POLYPROPYLENE/SANTOPRENE, BLACK, 2
PL-000101-00 INSULATOR, POWER SUPPLY, PL9.0, FISH PAPER, , 1
PL-000102-00 INSULATOR, AC LINE FILTER LEFT, PL9.0, FISH PAPER, , 1
PL-000103-00 INSULATOR, AC LINE FILTER RIGHT, PL9.0, FISH PAPER, , 1
PL-000104-00 INSULATOR, HIGH VOLTAGE, PL9.0, FISH PAPER, , 1
PL-000106-00 INSULATOR, HEAT SINK RIGHT, PL9.0, FISH PAPER, , 2
