QSC PowerLight Series - Page 34

32 QSC Audio Products, Inc.
TD-000083-00
QD-000182-00
Diode, 1200V, 60A, , 60EPS12, TO-247AD
QD-000183-00
Diode, 600V, 60A, 60EPS08, TO-247AD, PL9.0
QD-000228-00
Diode, 600V, 60A, 60EPS08, TO-247AD, PL6.0
KA
K (back of case)
QD-001340-LR
LED red, T-1 3/4, voltage reference
QD-000229-10
Diode, 250V, 0.25A, , BAV21, DO-35, 50NS
QD-004148-DX
Diode, 75V, 0.075A, 1N4148, DO-35, 4ns
AK
QD-000235-00
Rectifier dual common cathode, 500V, 30A, BYV74W-500, TO-247
A1 K
A2
K (back of case)
QD-000243-00
IGBT, 600V, 32A, 140W, IXGR32N60C, TO-247
GEC
G
C
E
QD-000188-00
MOSFET N-CHANNEL, 500V, 55A, 600W, IXFN55N50, SOT-227B
DS
GS
ANODE
CATHODE
