64 QSC Audio Products, Inc.
TD-000083-00
QD-000103-30 TRANSISTOR NPN, 40V, 0.2A, 0.2W, MMST3904, SOT-23, 7 Q10, Q4, Q5, Q7, Q8, Q9,
Q3
QD-000104-30 TRANSISTOR PNP, 40V, 0.2A, 0.2W, MMST3906, SOT-23, 3 Q12, Q2, Q14
QD-000114-30 DIODE ZENER, 150V, , 600W PEAK, P6SMB150AT3, SMB, 1 D3
QD-000115-30 DIODE RECTIFIER ULTRAFAST, 600V, 1A, , MURS160T3, SMB, 75NS 2 D4, D5
QD-000116-30 DIODE RECTIFIER ULTRAFAST, 200V, 1A, , MURS120, SMB, 35NS 4 D2, D8, D9, D10
QD-000136-30 DIODE ZENER, 7.5V, , 0.3W, BZX84C7V5, SOT-23, 1 D7
QD-000163-30 LED RED, , , , , SML-010, VOLTAGE REFERENCE 1 LD1
QD-000168-30 DIODE SCHOTTKY, 70V, 0.2A, , BAS70-04, SOT-23, 2 D14, D12
RE-007502-30 75, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R72
RE-018201-30 182, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R15
RE-020002-30 200, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R2
RE-033205-30 332, 0.1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R18
RE-090901-30 909, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R37
RE-110002-30 1.00K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 15 R19, R20, R24, R25, R35,
R4, R43, R47, R51, R54, R80, R84, R98, R75, R46
RE-110502-30 1.05K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R86, R22
RE-115002-30 1.50K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 4 R16, R17, R7, R70
RE-120002-30 2.00K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R48
RE-124902-30 2.49K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R50, R97
RE-130102-30 3.01K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R13, R14
RE-134802-30 3.48K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R68
RE-147502-30 4.75K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 8 R32, R34, R60, R90, R92,
R38, R33, R23
RE-160401-30 6.04K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 4 R36, R44, R45, R79
RE-161900-30 6.19K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R29
RE-163402-30 6.34K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R5
RE-178702-30 7.87K, 0.1 PCNT, 1/10W, THICK FILM, 0805, 100V 3 R57, R58, R83
RE-210003-30 10.0K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 9 R21, R31, R39, R73, R95,
R96, R91, R93, R94
RE-212702-30 12.7K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 3 R41, R52, R78
RE-215002-30 15.0K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 4 R101, R82, R85, R87
RE-221502-30 21.5K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 7 R10, R56, R59, R65, R74,
R81, R71
RE-224901-30 24.9K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R9, R11
RE-227401-30 27.4K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R28
RE-239203-30 39.2K, 0.1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R55
RE-245302-30 45.3K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R3
RE-247503-30 47.5K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 2 R69, R77
RE-310002-30 100K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 9 R26, R27, R30, R6, R66,
R67, R76, R8, R88
RE-314001-30 140K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R12
RE-375001-30 750K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R40
XF-000037-00 TRANSFORMER, HOUSEKEEPING, , , , PL9.0, , POWER SUPPLY 1 T1
Display PCB Assembly (QSC part number WP-000176-00)
Where used: All models, all voltages
This is a subassembly of each model’s respective chassis assembly; one per amplifier.
QSC Part # Description Qty Comments Ref erence
CA-147001-10 470PF, 10 PCNT, 100V, CERAMIC Y5E, DISC, 2 C502, C602
CA-410004-10 0.1UF, 20 PCNT, 50V, CERAMIC Z5U, DIPPED, 2 C507, C607
CA-422001-10 0.22UF, 5 PCNT, 50V, FILM, DIPPED, LOW PROFILE 4 C501, C505, C601, C605
CA-647003-10 47UF, 10 PCNT, 10V, ELECTROLYTIC, , NON-POLAR LOW PROFILE 2 C503, C603
CA-710035-BE 100UF, 20 PCNT, 35V, ELECTROLYTIC, , NON-AI 4 C504, C506, C604, C606
CO-000048-CO HEADER, 0.1" CENTERS, 16 POS (2X8), MALE, TERMINAL STRIP GOLD 2 J501, J601
IC-000072-OP OPAMP, DUAL, TL072, , 2 U501, U601
PC-000176-00 DISPLAY, PL9.0, , 1
PL-000127-00 SPACER, T-1 LED, 0.48", PLASTIC, BLACK, 14 ASSEMBLE W/ QD-000052-00, QD-000053-00, QD-000054-0
Power Supply Controller Assembly WP-000174-00 (continued)
QSC Part # Description Qty Comments Ref erence
