66 QSC Audio Products, Inc.
TD-000083-00
Line Filter Assembly (QSC part number WP-000181-00)
Where used: All models, 230 volts
This is a subassembly of the chassis assembly; one per amplifier.
QSC Part # Description Qty Comments Reference
CA-215001-00 0.0015UF, 20 PCNT, 125VAC, CERAMIC, DISC, YCAP 4 C10, C11, C8, C9
CA-347400-BP 0.047UF, 10 PCNT, 400V, FILM, DIPPED, 2 C12, C13
CA-510006-00 1.0UF, 20 PCNT, 250VAC, FILM, BOX STYLE, XCAP 4 USE .050 SPACER C1, C6, C2, C4
HW-000001-FC FUSE CLIP, PC MOUNT, , , TIN PLATED BRASS, 3AG 8 F1,3,F5,6
HW-000007-HW FUSE CLIP, PC MOUNT, , , TIN PLATED BRASS, 5MM 4 F2,4
HW-080080-PS STUD, PEM STYLE, #8-32, 0.500" L, TIN PLATED BRONZE, 2
MS-000113-00 FUSE, 1A, 250V, 5MM X 20MM, SLO-BLO 2 F2, F4
MS-150250-FU FUSE, 15A, 250V, 0.25" X 1.25", FAST 4 F1, F3, F5, F6
NW-060000-PI PRESS-IN NUT, #6-32, PCB MOUNT, CARBON STEEL, 4 L1,4,L5,7
PC-000177-00 AC LINE FILTER, PL9.0, , 1
QD-000157-10 DIODE, 1000V, 1.5A, , 1N5399, DO-15, 2 D1, D2
RE-000220-MV MOV, 275VAC, 140 JOULES, 1 R1
RE-375005-BM 750K, 5 PCNT, 1/2W, METAL FILM, , 5 (C5 LOCATION: FIX#15,LNGT 1.000) C5, R2, R3, R4, R5
SC-060061-PP PHILLIPS, PANHEAD, #6-32, 0.375" L, BLACK, 4 L1,4,5,7 (USE ELECTRICAL DRIVER WITH TORQUE SET #5)
WC-000096-00 WIRE ASSY, AC SWITCH, 10 AWG, 1 CONDUCTOR, PL9.0, 4.5" L, 4 E1,2,E5,6(FLAT SIDE CONN FACE-IN ON BOTH SIDE)
WC-000121-00 WIRE ASSY, POWER SUPPLY, 10 AWG, 1 CONDUCTOR, PL9.0, 17" L, BLACK 1 E7
WC-000121-01 WIRE ASSY, POWER SUPPLY, 10 AWG, 1 CONDUCTOR, PL9.0, 26" L, BLACK 1 E3
WC-000122-00 WIRE ASSY, POWER SUPPLY, 10 AWG, 1 CONDUCTOR, PL9.0, 20" L, WHITE 1 E9
WC-000122-01 WIRE ASSY, POWER SUPPLY, 10 AWG, 1 CONDUCTOR, PL9.0, 29" L, WHITE 1 E8
WC-000126-00 CABLE ASSY, HOUSEKEEPING, 20 AWG, 2 CONDUCTOR, PL9.0, 21" L, 1 E17(WHITE WIRE),E18(BLACK WIRE)
WC-000126-01 CABLE ASSY, HOUSEKEEPING, 20 AWG, 2 CONDUCTOR, PL9.0, 26" L, 1 E11(WHITE WIRE),E12(BLACK WIRE)
XF-000049-00 INDUCTOR, COMMON MODE, , 120UH, , , 2 L9, L8
XF-000069-00 INDUCTOR, LINE FILTER, TOROID, 43UH, PL9.0, , 2 L4, L7
XF-000070-00 INDUCTOR, COMMON MODE, TOROID, 8.5MH, PL9.0, , 2 (RED: 2,4; BLK:1,3; USE SMALL HOLE) L1, L5
LB-160226-01 FUSE, 15A, 250V, , UL 2
Line Filter Assembly (QSC part number WP-000177-00)
Where used: All models, 120 volts
This is a subassembly of the chassis assembly; one per amplifier.
QSC Part # Description Qty Comments Ref erence
CA-222001-00 0.0022UF, 20 PCNT, 125VAC, CERAMIC Y5U, DISC, YCAP 4 C10, C11, C8, C9
CA-347400-BP 0.047UF, 10 PCNT, 400V, FILM, DIPPED, 2 C12, C13
CA-447001-00 0.47UF, 20 PCNT, 250VAC, FILM, BOX STYLE, XCAP 5 USE .050 SPACER C1, C2, C4, C5, C6
HW-000001-FC FUSE CLIP, PC MOUNT, , , TIN PLATED BRASS, 3AG 8 F1, F3, F5, F6
HW-000007-HW FUSE CLIP, PC MOUNT, , , TIN PLATED BRASS, 5MM 4 F2, F4
HW-080080-PS STUD, PEM STYLE, #8-32, 0.500" L, TIN PLATED BRONZE, 2
MS-000112-00 FUSE, 25A, 125V, 0.25" X 1.25", NORMAL-BLO 4 F1, F3, F5, F6
MS-000113-00 FUSE, 1A, 250V, 5MM X 20MM, SLO-BLO 2 F2, F4
NW-060000-PI PRESS-IN NUT, #6-32, PCB MOUNT, CARBON STEEL, 4 L1, L4, L5, L7
PC-000177-00 AC LINE FILTER, PL9.0, , 1
QD-000157-10 DIODE, 1000V, 1.5A, , 1N5399, DO-15, 2 D1, D2
RE-000240-MV MOV, 150VAC, 80 JOULES, 1 USE .050 SPACER R1
RE-375005-BM 750K, 5 PCNT, 1/2W, METAL FILM, , 3 R2, R3, R4
SC-060061-PP PHILLIPS, PANHEAD, #6-32, 0.375" L, BLACK, 4 L1, L4, L5, L7 (USE ELECTRICAL DRIVER
WITH TORQUE SET #5)
WC-000096-00 WIRE ASSY, AC SWITCH, 10 AWG, 1 CONDUCTOR, PL9.0, 4.5" L, 4 E1, E2, E5, E6 (FLAT SIDE CONN FACE-IN
ON BOTH SIDE)
WC-000121-00 WIRE ASSY, POWER SUPPLY, 10 AWG, 1 CONDUCTOR, PL9.0, 17" L, BLACK 1 E7
WC-000121-01 WIRE ASSY, POWER SUPPLY, 10 AWG, 1 CONDUCTOR, PL9.0, 26" L, BLACK 1 E3
WC-000122-00 WIRE ASSY, POWER SUPPLY, 10 AWG, 1 CONDUCTOR, PL9.0, 20" L, WHITE 1 E9
WC-000122-01 WIRE ASSY, POWER SUPPLY, 10 AWG, 1 CONDUCTOR, PL9.0, 29" L, WHITE 1 E8
WC-000126-00 CABLE ASSY, HOUSEKEEPING, 20 AWG, 2 CONDUCTOR, PL9.0, 21" L, 1 E17(WHITE WIRE),E18(BLACK WIRE) WIRE LENGTH 26" INCHES
WC-000126-01 CABLE ASSY, HOUSEKEEPING, 20 AWG, 2 CONDUCTOR, PL9.0, 26" L, 1 E11(WHITE WIRE),E12(BLACK WIRE) WIRE LENGTH 26" INCHES
XF-000049-00 INDUCTOR, COMMON MODE, , 120UH, , , 2 L8, L9
XF-000071-00 INDUCTOR, LINE FILTER, TOROID, 4.6UH, PL9.0, , 2 L4, L7
XF-000072-00 INDUCTOR, COMMON MODE, TOROID, 1.5MH, PL9.0, , 2 (RED: PIN#2,4; BLK: PIN#1,3; BIG HOLE) L5, L1
To Next Page
