QSC PowerLight Series - Input PCB Assembly (QSC Part # WP-000265-00); Input PCB Assembly (QSC Part # WP-000175-00)

PowerLight 9.0
PFC
, PowerLight 6.0
PFC
, PowerLight 6.0 II Service Manual 41
Parts lists
Input PCB Assembly (QSC part # WP-000175-00)
Where used: PowerLight 6.0
PFC
, 120 and 230 volts.
This is a subassembly of the Chassis Assembly, Rear (WP-000179-00); one per amplifier.
QSC Part # Description Qty Comments Reference
CA-122001-10 220PF, 10 PCNT, 100V, CERAMIC NPO, DISC, 4 C300, C302, C400, C402
CA-410004-10 0.1UF, 20 PCNT, 50V, CERAMIC Z5U, DIPPED, 4 C301, C303, C401, C403
CO-000168-00 XLR, COMBO, 3 POS, FEMALE, VERTICAL 2 J301, J401
IC-000072-OP OPAMP, DUAL, TL072, , 2 U300, U400
PC-000175-00 INPUT, PL9.0, , 1
QD-000062-10 TRANSISTOR NPN, 40V, 0.2A, 1.5W, 2N3904, TO-92, 1 Q1
QD-001340-LR LED RED, , , , , T-1 3/4, VOLTAGE REFERENCE 2 FLUSH TO THE PCB, CUT & CLINCH BOTH LEADS, AVOID TRACES LD1, LD2
QD-004148-DX DIODE, 75V, 0.075A, , 1N4148, DO-35, 4NS 2 D1, D2
RE-003305-BC 33, 5 PCNT, 1/4W, CARBON FILM, , 1 R10
RE-004751-BM 47.5, 1 PCNT, 1/4W, METAL FILM, , 3 R13, R306, R406
RE-084501-10 845, 1 PCNT, 1/4W, METAL FILM, , 1 R12
RE-110001-10 1.00K, 1 PCNT, 1/3W, METAL FILM, , 8 R300–R303, R400–R403
RE-134802-10 3.48K, 1 PCNT, 1/8W, METAL FILM, , 4 R1, R2, R3, R22
RE-190901-BM 9.09K, 1 PCNT, 1/4W, METAL FILM, , 5 R4, R304, R305, R404,
R405
RE-220001-10 20.0K, 1 PCNT, 1/3W, METAL FILM, , 2 R20, R23
SW-000043-00 SWITCH, 4P3T, SLIDE, PCB MOUNT 1 SW1
WC-000128-00 RIBBON CABLE ASSY, , 28 AWG, 16 CONDUCTOR, PL9.0, 8.75" L, 2
WP-000178-00 PCB ASSY, INPUT DAUGHTER, PL6.0/PL9.0, , 1
Input PCB Assembly (QSC part # WP-000265-00)
Where used: PowerLight 6.0
PFC
, 120 and 230 volts.
This is a subassembly of the Chassis Assembly, Rear (WP-000264-00); one per amplifier.
QSC Part # Description Qty Comments Reference
CA-122001-10 220PF, 10 PCNT, 100V, CERAMIC NPO, DISC, 4 C300, C302, C400, C402
CA-410004-10 0.1UF, 20 PCNT, 50V, CERAMIC Z5U, DIPPED, 4 C301, C303, C401, C403
CO-000168-00 XLR, COMBO, 3 POS, FEMALE, VERTICAL 2 J301, J401
IC-000072-OP OPAMP, DUAL, TL072, , 2 U300, U400
PC-000175-00 INPUT, PL9.0, , 1
QD-000062-10 TRANSISTOR NPN, 40V, 0.2A, 1.5W, 2N3904, TO-92, 1 Q1
QD-001340-LR LED RED, , , , , T-1 3/4, VOLTAGE REFERENCE 2 FLUSH TO THE PCB, CUT & CLINCH BOTH LEADS, AVOID TRACES LD1, LD2
QD-004148-DX DIODE, 75V, 0.075A, , 1N4148, DO-35, 4NS 2 D1, D2
RE-003305-BC 33, 5 PCNT, 1/4W, CARBON FILM, , 1 R10
RE-004751-BM 47.5, 1 PCNT, 1/4W, METAL FILM, , 3 R13, R306, R406
RE-110001-10 1.00K, 1 PCNT, 1/3W, METAL FILM, , 8 R300–R303, R400–R403
RE-122601-10 2.26K, 1 PCNT, 1/4W, METAL FILM, , 1 R12
RE-134802-10 3.48K, 1 PCNT, 1/8W, METAL FILM, , 4 R1, R2, R3, R22
RE-190901-BM 9.09K, 1 PCNT, 1/4W, METAL FILM, , 5 R4, R304, R305, R404,
R405
RE-220001-10 20.0K, 1 PCNT, 1/3W, METAL FILM, , 2 R20, R23
SW-000043-00 SWITCH, 4P3T, SLIDE, PCB MOUNT 1 SW1
WC-000128-00 RIBBON CABLE ASSY, , 28 AWG, 16 CONDUCTOR, PL9.0, 8.75" L, 2
WP-000178-00 PCB ASSY, INPUT DAUGHTER, PL6.0/PL9.0, , 1
