PowerLight 9.0
PFC
, PowerLight 6.0
PFC
, PowerLight 6.0 II Service Manual 53
Parts lists
CA-347002-30 0.047UF, 20 PCNT, 50V, CERAMIC Z5U, 0805, 9 C3, C4, C11–C13, C15,
C28, C64, C81
CA-410011-00 0.1UF, 10 PCNT, 400V, FILM, DIPPED, 3 C14, C107, C123
CA-410012-30 0.1UF, 10 PCNT, 25V, CERAMIC X7R, 0805, 9 C7, C17, C19, C20, C61,
C65, C125, C135, C162
CA-410006-30 0.1UF, 10 PCNT, 50V, CERAMIC X7R, 1206, 1 C18
CA-422004-30 0.22UF, 10 PCNT, 50V, CERAMIC X7R, 1206, 1 C155
CA-447003-00 0.47UF, 10 PCNT, 400V, FILM, WRAPPED, PULSE 2 C37, C38
CA-510006-00 1.0UF, 20 PCNT, 250VAC, FILM, BOX STYLE, XCAP 1 C23
CA-515002-30 1.5UF, 20 PCNT, 35V, TANTALUM, 3216, 6 C6, C10, C21, C75, C77,
C79
CA-522003-00 2.2UF, 20 PCNT, 400V, ELECTROLYTIC, , 1 C73
CA-610006-30 10UF, 20 PCNT, 16V, ELECTROLYTIC, SMT, 1 C78
CA-610007-30 10UF, 20 PCNT, 6.3V, TANTALUM, 3528, 6 C9, C31, C32, C52, C80,
C114
CA-710004-10 100UF, 20 PCNT, 25V, ELECTROLYTIC, , LOW ESR 4 C71, C72, C74, C76
CA-810004-00 1000UF, 20 PCNT, 55V, ELECTROLYTIC, , 20 C151–C154, C158–C161,
C164–C175
CA-822200-AE 2200UF, 20 PCNT, 200V, ELECTROLYTIC, , 6 C132, C133, C136, C137,
C140, C141
CH-000103-00 CLAMP, TO-3PL, 22 GA, PLX3002, 3
CH-000262-00 HEAT SINK, PFC, 11", EVICTOR, 1
CH-000263-00 HEAT SINK, MAIN SUPPLY, 13.5", EVICTOR, 1
HW-000036-00 STANDOFF, 0.344" ROUND, #8, 0.187" L, ALUMINUM, SWAGE 4
HW-080080-PS STUD, PEM STYLE, #8-32, 0.500" L, TIN PLATED BRONZE, 2 E1, E2
IC-000024-00 CONTROLLER, PWM, SG3525AN, , 1 U19
IC-000031-00 OPTO ISOLATOR, , 4N30, , 1 U15
IC-000051-00 OPTO ISOLATOR, , MOC8101, , 1 U1
IC-000053-30 TIMER, DUAL, LM556, , 1 U14
IC-000054-30 COMPARATOR, QUAD, LM339AM, SMT, 1 U13
IC-000133-30 COMPARATOR, SINGLE, LM311, SMT, 2 U2, U3
IC-000134-00 DRIVER, MOSFET, IR2110, , 1 U18
IC-000235-00 TOP SWITCH, , TOP224, , 1 ASSY /W MS-000048-HS U29
MS-000048-HS HEAT SINK, TO-220, 1.375" X 0.86" X 0.395", LONG TAB, PLUG-IN 1 REF: U29
MS-000143-30 FUSE, 0.5A, 32V, 1206, FAST (MS-000115-30) 1 F1
PC-000266-00 POWER SUPPLY, EVICTOR, , 1
PL-000010-00 BUMPER, ADHESIVE BACKED, 0.5" X 0.5", POLYURETHANE, BLACK, 8
PL-000114-00 INSULATOR, IGBT/RECTIFIER, 1.25" X 3.20", THERMALLY CONDUCTIVE, , 2
PL-000121-00 SPACER, LED/TO-92, 0.18", PVC, BLACK, 1 REF: R28
PL-000126-00 SPRING SEAT, TRANSISTOR, PLX, NYLON, , 3
PL-000134-00 GROMMET, VIBRATION DAMPING, 0.375" OD, NEOPRENE, , 1
QD-000022-QD DIODE ZENER, 18V, , 1W, 1N4746A, DO-41, 1 D95
QD-000023-QD DIODE ZENER, 180V, , 1.5W, 1N5955A, DO-41, 8 D9–D14, D19, D20
QD-000042-00 DIODE RECTIFIER ULTRAFAST, 400V, 3A, , MUR440, DO-201AD, 50NS 2 D70, D71
QD-000047-00 DIODE ZENER, 200V, , 1.5W, 1N5956B, DO-41, 1 D2
QD-000074-00 DIODE RECTIFIER ULTRAFAST, 400V, 15A, , MUR1540, TO-220, 50NS 2 D75, D80
QD-000102-30 DIODE, 75V, 0.075A, , IMBD4148, SOT-23, 4NS 4 D4, D29, D72, D89
QD-000103-30 TRANSISTOR NPN, 40V, 0.2A, 0.2W, MMST3904, SOT-23, 11 Q3, Q92, Q93, Q102,
Q103, Q105, Q107–Q110,
Q114
QD-000104-30 TRANSISTOR PNP, 40V, 0.2A, 0.2W, MMST3906, SOT-23, 7 Q94, Q95, Q100, Q101,
Q104, Q111, Q112
QD-000108-30 DIODE, 200V, 0.2A, , BAS21, SOT-23, 50NS 1 D87
QD-000110-30 DIODE ZENER, 6.2V, , 0.3W, BZX84C6V2, SOT-23, 3 D21, D24, D28
QD-000113-30 DIODE ZENER, 10V, , 0.3W, BZX84C10, SOT-23, 2 D1, D5
QD-000115-30 DIODE RECTIFIER ULTRAFAST, 600V, 1A, , MURS160T3, SMB, 75NS 3 D58, D86, D100
QD-000116-30 DIODE RECTIFIER ULTRAFAST, 200V, 1A, , MURS120, SMB, 35NS 3 D25, D93, D96
QD-000125-00 DIODE RECTIFIER FAST, 600V, 37A, , DSEI30-06A, TO-247AD, 50NS 2 D77, D84
QD-000137-30 DIODE SCHOTTKY, 15V, 0.01A, , MMBD301LT1, SOT-23, VF MAX 0.6V 1 D3
QD-000163-30 LED RED, , , , , SML-010, VOLTAGE REFERENCE 1 LD1
QD-000170-00 BRIDGE RECTIFIER, 600V, 50A, , , , IN-LINE 1 BR1
QD-000229-10 DIODE, 250V, 0.25A, , BAV21, DO-35, 50NS 2 D22, D23
QD-000235-00 RECTIFIER DUAL COMMON CATHODE, 500V, 30A, , BYV74W-500, TO-247, 2 D73, D85
QD-000243-00 IGBT, 600V, 32A, 140W, IXGR32N60C, TO-247, 2 Q96, Q97
QD-000248-30 DIODE ZENER, 15V, , 350MW, BZX84C15TR, SOT-23, 2 D6, D27
Power Supply Assembly WP-000266-02 (continued)
QSC Part # Description Qty Comments Ref erence
