PowerLight 9.0
PFC
, PowerLight 6.0
PFC
, PowerLight 6.0 II Service Manual 43
Parts lists
CH-000091-00 CLAMP, TO-264, 5.1", PL9.0, 2
CH-000091-01 CLAMP, TO-264, 4.5", PL9.0, 3
CH-000074-00 HEAT SINK, AUDIO, 8", PL9.0, 3
CH-000075-00 HEAT SINK, AUDIO, 14", PL9.0, 1
CO-000074-00 HEADER, 0.1" CENTERS, 8 POS (1X8), MALE, RAMP LOCK 1 J4
CO-000033-CO HEADER, 0.1" CENTERS, 4 POS (1X4), MALE, RAMP LOCK 1 J5
CO-000056-CO HEADER, 0.1" CENTERS, 16 POS (2X8), MALE, LATCHING BOX 1 J7
CO-000124-00 BARRIER STRIP, 0.375" CENTERS, 5 POS, , SHORT PIN 1 J3
HW-080005-SO SPACER, 0.312" ROUND, #8, 0.187" L, BRASS, SWAGE 4
HW-080008-SO SPACER, 0.312" ROUND, #8, 0.187" L, ALUMINUM, SWAGE 11
IC-000046-30 OPAMP, DUAL, TLO72, SMT, 10 U2, U5, U6, U9, U15,
U17, U19, U20, U22, U23
IC-000047-30 COMPARATOR, DUAL, LM393, SMT, 2 U7, U8
IC-000048-30 OPAMP, DUAL, MC33078, , 1 U18
IC-000059-00 TOP SWITCH, , TOP202, , 1 U3
IC-000067-30 DIFFERENTIAL AMPLIFIER, DUAL, CA3054, SMT, 5 U21, U24–U26, U28
IC-000070-30 VOLTAGE REFERENCE, +2.5V, LM4040DIM3X-2.5, , 1 U1
IC-000071-00 SENSOR, TEMPERATURE, LM35DZ, , 1 U10
IC-000073-30 TRANSCONDUCTANCE OPAMP, DUAL, LM13600M, , 1 U16
MS-000102-00 SHIELD, ELECTRO-MAGNETIC, INSULATED, PL9.0, 1
NW-100300-00 PRESS-IN NUT, #10-32, , , 2
PC-000182-00 PCB MAIN, PL 9.0, , 1
PL-000091-00 INSULATOR, STEP SWITCH, PL9.0, THERMALLY CONDUCTIVE, , 1
PL-000092-00 ISOLATOR, SPRING, PL9.0, FR-4 PCB, , 1
PL-000094-00 INSULATOR, CAPACITOR, PL9.0, FISH PAPER, , 1
PL-000112-00 RIVET, , 0.156" X 0.322", PLASTIC, , 1
PL-000121-00 SPACER, LED/TO-92, 0.18", PVC, BLACK, 1
PL-905156-SP SPACER, ROUND, 0.047"ID X 0.25"OD X 0.155"L, NYLON, , 6
PL-905385-SP SPACER, ROUND, 0.047"ID X 0.25"OD X 0.385"L, NYLON, , 1
PT-250000-AT TRIM, 5K, 20 PCNT, 0.15W, , 1 VR1
QD-000024-QD DIODE ZENER, 6.2V, , 0.25W, DZ901116G, DO-35, 3 D96–D98
QD-000062-10 TRANSISTOR NPN, 40V, 0.2A, 1.5W, 2N3904, TO-92, 1 Q700
QD-000063-10 TRANSISTOR PNP, 40V, 0.2A, 1.5W, 2N3906, TO-92, 1 Q701
QD-000065-10 TRANSISTOR PNP, 300V, 0.5A, 1.5W, MPSA92, TO-92, 3 Q23, Q83, Q88
QD-000078-10 TRANSISTOR NPN DARLINGTON, 30V, 0.5A, 1.5W, MPSA13, TO-92, 3 Q3, Q16, Q26
QD-000080-20 DIODE ZENER, 11V, , 1W, 1N4741A, DO-41, 7 D29, D33, D48, D50, D53–
D55
QD-000102-30 DIODE, 75V, 0.075A, , IMBD4148, SOT-23, 4NS 49 D15, D18, D22, D23, D25,
D27, D28, D32, D35, D38,
D39, D51, D58, D59, D79,
D84, D85, D87, D88, D90–
D95, D706, D708, D713,
D715, D717–D720, D723–
D736
QD-000103-30 TRANSISTOR NPN, 40V, 0.2A, 0.2W, MMST3904, SOT-23, 56 Q2, Q5, Q8, Q10, Q13,
Q28, Q45, Q46, Q49,
Q50, Q53, Q56, Q58,
Q59, Q62, Q68, Q71,
Q73–Q77, Q81, Q84, Q86,
Q90, Q96, Q97, Q99,
Q100, Q102, Q104, Q107,
Q110, Q112, Q113, Q118,
Q120, Q121, Q125–Q127,
Q130, Q135, Q136, Q137,
Q702, Q704
QD-000104-30 TRANSISTOR PNP, 40V, 0.2A, 0.2W, MMST3906, SOT-23, 65 Q7, Q11, Q20, Q31, Q34,
Q54, Q55, Q57, Q60, Q64–
Q67, Q69, Q70, Q78, Q79,
Q82, Q85, Q91–Q95, Q98,
Q101, Q103, Q105, Q106,
Q108, Q109, Q111, Q114–
Q117, Q119, Q122–Q124,
Q128, Q129, Q131, Q132,
Q133, Q703, Q705
QD-000105-30 TRANSISTOR NPN, 300V, 0.2A, 0.2W, MMBTA42, SOT-23, 6 Q6, Q18, Q19, Q21, Q22,
Q30
QD-000106-30 TRANSISTOR PNP, 300V, 0.2A, 0.2W, MMBTA92, SOT-23, 4 Q9, Q15, Q32, Q169
QD-000107-30 JFET N-CHANNEL, 35V, , , PMBFJ112, SOT-23, RDS ON 50 OHMS 2 Q29, Q706
QD-000108-30 DIODE, 200V, 0.2A, , BAS21, SOT-23, 50NS 5 D6, D21, D24, D41, D42
Audio Channel Module Assembly WP-000276-00 (continued)
QSC Part # Description Qty Comments Ref erence
To Next Page
