PowerLight 9.0
PFC
, PowerLight 6.0
PFC
, PowerLight 6.0 II Service Manual 49
Parts lists
RE-022100-30 221, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 8 R22, R92, R136, R148,
R152, R173, R176, R178
RE-030900-30 309, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 16 R31, R38, R124, R125,
R127, R130, R133, R135,
R141, R155, R162, R167–
R169, R180, R181
RE-033203-30 332, 1 PCNT, 1/4W, THICK FILM, 1210, 200V 5 R206, R276, R347, R358,
R365
RE-047502-30 475, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 16 R4, R21, R107, R118,
R123, R129, R132, R145,
R147, R153, R159, R171,
R174, R177, R196, R410
RE-053602-30 536, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 16 R266, R280, R288, R296,
R328, R349, R359, R360,
R399, R412–R418
RE-110002-30 1.00K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 37 R16, R86, R90, R100,
R212, R239, R273, R285,
R301, R322, R323, R339,
R342, R354, R362, R373–
R375, R377, R380, R383,
R385, R386, R390–R392,
R397, R402, R404, R405,
R409, R702, R703, R713–
R715, R747
RE-113302-30 1.33K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 15 R10, R52, R61, R65,
R82,
R91, R93, R103, R122,
R246, R290, R299, R320,
R324, R744
RE-115002-30 1.50K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 8 R376, R378, R387–R389,
R398, R400, R406
RE-121501-30 2.15K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 1 R356
RE-122102-30 2.21K, 1 PCNT, 1/4W, THICK FILM, 1210, 200V 3 R84, R85, R151
RE-124902-30 2.49K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 3 R345, R355, R366
RE-128702-30 2.87K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 21 R9, R17, R19, R32, R51,
R67, R73, R89, R102,
R221, R229, R242, R247,
R249, R265, R267, R277,
R278, R341, R363,R711
RE-133006-30 3.3K, 0.1 PCNT, 1/10W, THICK FILM, 0805, 100V 6 R213, R228, R235,
R245, R297, R315
RE-134802-30 3.48K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 14 R11, R53, R55, R71,
R74,
R75, R87, R143, R222,
R236, R275, R282, R284,
R351
RE-145302-30 4.53K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 5 R13, R35, R59, R104,
R340
RE-147005-DM 4.7K, 5 PCNT, 1W, METAL OXIDE FP, , 4 USE .050 SPACER, HAND PREP, VERT. POSITION R732–R735
RE-156001-10 5.60K, 0.1 PCNT, 1/4W, METAL FILM, , 25PPM 21 R25, R29, R34, R37,
R40,
R45, R192, R200, R207,
R209, R224, R305–R312,
R332, R335
RE-156001-10 5.60K, 0.1 PCNT, 1/4W, METAL FILM, , 25PPM 2 R88, R96
RE-159002-30 5.90K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 14 R7, R48, R49, R101,
R108, R160, R251, R294,
R295, R333, R336, R337,
R346, R357
RE-175002-30 7.50K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 10 R8, R63, R243, R262,
R272, R286, R325, R728,
R729, R745
RE-210003-30 10.0K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 10 R50, R198, R220, R231,
R274, R298, R300, R709,
R710, R741
RE-215002-30 15.0K, 1 PCNT, 1/10W, THICK FILM, 0805, 100V 16 R14, R47, R57, R69,
R77,
R99, R149, R197, R205,
R223, R271, R303, R313,
R314, R319, R343
RE-222006-BM 22K, 5 PCNT, 1W, METAL OXIDE FP, , 1 R737
Audio Channel Module Assembly WP-000182-00 (continued)
QSC Part # Description Qty Comments Ref erence
