Quadra-Fire CASTILE - Thermostat Location; Tools And Supplies Needed; Inspect Appliance and Components; Pre-Burn Check List

R
October 27, 2011
Page19
Castile & Santa Fe CE Insert
7069-101B
B. Thermostat Location
The thermostat’s location will have some effect on the
appliance’soperation.
Whenthethermostatislocatedclosetotheappliance,itmay
requireaslightlyhighertemperaturesettingtokeeptherest
ofthehousecomfortable.
If the thermostat location is in an adjacent room or on a
differentoorlevel,youwillnoticehighertemperaturesnear
theappliance.
7/16inchSocketWrench
(or10mm6ptor11mm6
ptsocket)
FramingSquare
ElectricDrill&Bits
Self-TappingScrews
OutsideAirRequired
ClassLorPLPelletVent
Mayalsoneed:
VentSupportStraps
ReciprocatingSaw
Hammer
PhillipsScrewdriver
TapeMeasure
PlumbLine
Level
FramingMaterial
Hi-tempCaulkingMaterial
Gloves
SafetyGlasses
Tools and building supplies normally required for instal-
lation.
C. Tools And Supplies Needed
D. Inspect Appliance and Components
WARNING! Risk of Fire! Damagedpartscouldimpairsafe
operation.DoNOTinstalldamaged,incompleteorsubstitute
components.
• Opentheapplianceandremoveallthepartsandarticles
packedinsidetheComponentPack.Inspectalltheparts
andglassforshippingdamage.
• Reporttoyourdealeranypartsdamagedinshipment.
• Alllabelshavebeenremovedfromtheglassdoor.
• Platedsurfaceshavebeenwipedcleanwithasoftcloth,
ifapplicable.
• Read all the instructions before starting the installation.
Follow these instructions carefully during the
installation to ensure maximum safety and benet.
• Follow pipe manufacturer instructions for installation
and air clearance requirments.
E. Pre-Burn Check List
1. Placetheapplianceinalocationnearthe
nalinstallationareaandfollowtheproce-
duresbelow:
2. Opentheapplianceandremovealltheparts
and articles packed inside the Component
Pack.Inspectallthepartsandglassforship-
pingdamage.Contactyourdealerifanyirregu-
laritiesarenoticed.
3. All safety warnings have been read and fol-
lowed.
4.
ThisOwner’sManualhasbeenread.
5. Floorprotectionrequirementshavebeenmet.
6. Ventingisproperlyinstalled.
7. Theproperclearancesfromtheapplianceand
chimney to combustible materials have been
met.
8.
Themasonrychimneyisinspectedbyaprofes-
sionalandis clean, or thefactorybuilt metal
chimneyisinstalledaccordingtothemanufac-
turer’sinstructionsandclearances.
9. The chimney meets the required minimum
height.
10.
All labels have been removed from the glass
door.
11. Plated surfaces have been wiped clean, if
applicable.
12.
Thermostatorremotehasbeeninstalled.
13. Apoweroutletisavailablenearby.
