Quadra-Fire CASTILE - Optional Log Set Placement

Page34
October 27, 2011
R
Castile & Santa Fe CE Insert
7069-101B
1. Opendoortoexposetherebox.
2. Installtheleftlogrstandthentherightlog.Figure 37.1
3. Leanthelogsagainstthecastironbrickinthebackof
therebox.
4. Push the logs to the far left and far right against the
sidesoftherebox.Figure 37.2.
5. Tocleanthelogs,useavaccumandasoftbrushattach-
mentorapaintbrush.
Two Piece Log Set Installation
Figure 37.2
J. Optional Log Set Placement Instructions
CAUTION
LogsareFRAGILE.Useextremecarewhenhandlingor
cleaninglogs.
NOTE:
Duetotheabrasivenatureofapelletappliancere,the
logsarenotcoveredunderwarranty.Anyplacementvari-
ation other than shown here can cause excessive heat
andshallvoidtheappliancewarranty.
Figure 37.1
