Quadra-Fire CASTILE - Hearth Support for Standard Surround

Page30
October 27, 2011
R
Castile & Santa Fe CE Insert
7069-101B
Figure 32.2
1
2
3
4
5
6
7
8
F. Hearth Support For Standard Surround Only
Figure 33.1 - Assembled View
Item Description
1
Front,76mm
2 Front,127mm
3 CastRing,Top&Bottom,Interchangeable
4 Side,127mm
5 Side,76mm
6
PanelExtension,127mm
7 PanelExtension,76mm
8 PanelExtension,BasePlateOnly
Install Sides
First
Install Front Last
Bend top and bottom tabs toward inside
NOTE: Manually
pre-shape sides before
installing
Turn right side up and attach top cast ring
Panel Extension
Alignment
Hole
Cast Trim Footer
Panel Leg
1. Removecontentsfromboxandlayonprotectivesurfaceto
avoidscratchingthepaint.
2. Layhearthsupport’sfrontandsidesfacedown.Bendthe
tabdowntowardtheinside.
3. Thesidepiecesareshippedat.It ismucheasiertomanually
exthesidesintoabowedpositionbeforeinstalling.
4. Lay1castringfaceup,which willbecomethebottomringwhen
installed.Attachthe2sidesFIRSTandthenthefrontpiece.
Figure 33.3.
5
. Nowturnthecastringrightsideup andattachthetopcast
ring. Figure 33.4.
6. Attachthehearthsupport’spanelextensions.Figure 33.5
7. Attachcastfooters. Figure 33.6.
8
. Placetheassembledhearthsupportundertheinsert.Figure
33.7.
Figure 33.3
Figure 33.4
Figure 33.5
Figure 33.6
Figure 33.7
