Operation Page 55 of 85
Error Messages (FAIL result)
When the measurement value was judged NO GOOD and FAIL is shown on the display, an error
message denoting the test result will be shown on the display also. Table 2-4 lists the possible
error messages for a NO GOOD/FAIL judgment.
Table 2-4: Error Messages
Error Message Description
HIGH FAIL Measured value (current or resistance) is over the programmed high limit.
LOW FAIL Measured value (current or resistance) is below the programmed low limit.
ARC FAIL Current arc is over the programmed high limit.
I/O FAIL Hardware Current Limit exceeded. Check DUT for short.
VOLTAGE OVER Voltage reading is greater than the hardware allowable # of digits.
CURRENT OVER Current reading is greater than the hardware allowable # of digits.
GFI TRIPPED Ground Fault Interrupt is No Good.
NO OUTPUT Output is too Low. (Try increasing test time)
INRUSH FAIL Charging Current is over limit. (Check test fixture)
MEMORY FULL Greater than 60 tests/slot have been stored.
