QuadTech Sentry 30 Plus User Manual

Page 9 of 85
Specifications (Continued)
General Features
Setup Storage: 60 Memory Locations, 10 steps each
Standard
Interfaces: Remote I/O
Connectors: Front and Rear Connection
HV OUTPUT: Custom Banana Socket
RTN/LOW: Banana Socket
GC (Rear Only): Binding Post/Banana Socket
Front Panel 10 Digit Password with or without setup recall
Lockout: LED Display: LOCK
Mechanical: Bench Mount
Dimensions:(w x h x d): 10.50 x 4.50 x 14.25 inches
262.5 x 112.5 x 356.25 mm
Weight: 25.0 lbs (11.5 kg) net, 28 lbs (13.0 kg) shipping
Environmental: Specifications: 18°C to 28°C, 70% RH
Operating: 0°C to + 40
o
C, 80% RH
Storage: -10°C to + 60
o
C, 80% RH
Warm-up Time: 15 minutes
Power: • 90 - 130V AC • 50 or 60Hz
• 200 - 250V AC • 300W max
Supplied:
• Instruction Manual • Power Cable
• Calibration Certificate • S02 Test Leads
• Ground Continuity Lead
Safety Agency: CE, TUV
Ordering Description Catalog No.
Information: AC Hipot Tester Sentry 10 Plus
AC/DC Hipot Tester Sentry 20 Plus
AC/DC/IR Hipot Tester Sentry 30 Plus
