QUANTA QuantaGrid S31A-1U User Manual

BMC CONFIGURATION GROUP
3-51
The fields of RADIUS Settings Page are explained below.
Procedure:
1. Enable the RADIUS Authentication checkbox to authenticate the RADIUS.
2. Click on Advanced Settings button. This opens the Radius Authorization window
as shown below.
 For Authorization Purpose, configure the Radius user with Vendor Specific Attri-
bute in Server side.
Example:1
testadmin Auth-Type :=PAP,Cleartext-Password:=”admin”
Auth-Type :=PAP, Vendor-Specific=”H=4”
Example:2
testoperator Auth-Type := PAP,Cleartext-Password := “operator”
Auth-Type :=PAP, Vendor-Specific=”H=3”
If you change the Vendor-Specific value in server then you should change the
same values in this page.
3. Click Save to save the changes made else click Cancel to go back to the previous
screen.
Table 19: RADIUS Settings Page
ITEM DESCRIPTION
RADIUS Authentication Option to enable RADIUS authentication.
Port
The RADIUS Port number.
Note:
Default Port is 1812.
Port value ranges from 1 to 65535.
Server Address
The IP address of RADIUS server.
Note:
 IP Address made of 4 numbers separated by dots as in "xxx.xxx.xxx.xxx".
 Each Number ranges from 0 to 255.
 First Number must not be 0.
Secret
The Authentication Secret for RADIUS server.
Note:
 This field will not allow more than 31 characters.
 Secret phrase must be at least 4 characters long.
 White space is not allowed.
Extended Privileges This field is used to assign KVM and VMedia privilege for the user.
Advanced Settings For setting the advanced features.
Save To save the settings.
Reset To reset the modified changes.
