QUANTA QuantaGrid S31A-1U User Manual

ABOUT THE SYSTEM INTRODUCTION
1-2
Storage controller
Onboard (Intel® C236):
 2 mini-SAS HD connectors suppoting 8x SATA 6Gb/s ports
 2x M.2 connector supporting SATA or PCIe SSD
Optional controller:
 Please refer to our Compatible Component List for more information
Networking
LOM:
 2x Intel® I210 GbE port
 Dedicated GbE management port
Optional NIC:
 Please refer to our Compatible Component List for more information
Expansion slot
Riser
 PCIe Expansion Card Riser: One x 8 PCIe 3.0, Low profile MD-2
 QCT mezzanine Riser: One x8 PCIe 3.0, SAS mezzanine slot
OCP mezzanine slot
 One x8 PCIe 3.0 slot
Storage
 4x 3.5" hot-plug SAS/SATA HDD/SSD
 2x 2.5” internal SATA SSD
Onboard storage 2x M.2 SSD (SATA or PCIe)
Video Integrated Aspeed AST2400 with 8MB DDR3 video memory
Front I/O
 Power/ID/Reset Buttons
 LAN/HDD/Status/ID LEDs
 2x USB 2.0 ports
Rear I/O
 2x USB 3.0 ports
 1x VGA port
 1x RS232 serial port
 2x GbE RJ45 port
 1x GbE RJ45 management port
 1x ID button with LED
TPM Yes (optional)
Power supply
SKU1: 1+1 redundant hot-plug PSU, 80 Plus Platinum
 3Y 700W 100-240Vac, 50-60Hz, 10-5A
 3Y 400W 100-240Vac, 50-60Hz, 6-3A
 Acbel 700W 100-127/200-240Vac, 50/60Hz, 9.5/5A
 Acbel 400W 100-127/200-240Vac, 50/60Hz, 6/3A
SKU2: 1x fixed PSU, 80 Plus Platinum
Rating (per PSU inlet) 100-127/200-240Vac, 50/60Hz, 4/2A
Fan 3x dual rotor fans (5+1 redundant)
System management IPMI v2.0 Compliant, on board "KVM over IP" support
Operating environment
 Operating temperature: 5°C to 40°C (41°F to 104°F)
 Non-operating temperature: -40°C to 70°C (-40°F to 158°F)
 Operating relative humidity: 50% to 85%RH.
 Non-operating relative humidity: 20% to 90%RH
Table 1.1: System Specifications (Continued)
SPECIFICATIONS DESCRIPTION

QUANTA QuantaGrid S31A-1U Specifications

General

Brand	QUANTA
Model	QuantaGrid S31A-1U
Category	Server
Language	English
