NOTE:
The packing box is heavy. It is recommended for two persons to carry the box and
perform the installation.
Placetheboxonaatandstablesurfaceandcutthestrapssecuringthebox.1.
Removethehardwareandplaceitonaatandcleansurface.2.
Remove all other items from the box.3.
Inspect each item to make sure all items are included and free from damage (see 4. “Select the
Location” on page 17).
Keep the packaging box in case you need to transport the switch.5.
Install the Switch3.2
For a successfully installation, perform the steps below in the following order:
Select the location (see 1. “3.2.1 Select the Location” on page 17).
Install the switch (see 2. “3.2.2 Install the Switch” on page 18).
Connect the Power Source (see 3. “3.3 Connect to Power” on page 20).
Check the installation (see 4. “3.4 Check the Installation” on page 20).
Select the Location3.2.1
The switch can be installed in the following ways:
Flatsurfaceinstallation:Placedasastandaloneunitonaatsurface.•
Rack-mounted installation: Installed in a standard rack•
Installation and Safety Considerations3.2.1.1
Consider the following when choosing an installation location:
The installation location allows you to view and access the front and rear panel ports.•
The installation location is located within a proper distance to the power source. The power •
source must be properly grounded and readily accessible.
The installation location allows you to route and organize cables for easy cable management •
and maintenance.
Theinstallationlocationisfreefromstrongelectromagneticeldsources,suchasradiators,•
motors, and heat sources.
The installation location is not exposed to direct sunlight, rain or moisture.•
The installation surroundings must have adequate ventilation. Proper clearance between the •
switch and the wall or other equipment must be observed.
If installing on a rack, ensure the cabinet is stable and secure to withstand any unexpected •
movement, such as an earthquake. Ensure the rack or cabinet can support the weight of the
switch and other additional weight.
