QUANTA QuantaMesh T3048-LY2R - Figure 3-4: Pull out Rack Rail; Figure 3-5: Install Switch on Rail

ENGLISH
19
Hardware Installation
Pull out the internal rail.3.
Pull Out Rack RailFigure 3-4:
Align the brackets to the rail holes and secure them with screws.4.
Install Switch on RailFigure 3-5:
