QUANTECH
128
SECTION 8 - MICROPANEL
FORM QTC4-NM1
ISSUE DATE: 4/2/2018
VSD Internal Ambient Temp
VSD INTERNAL AMBIENT TEMP = XXX.X °F
COOLING SYSTEM STATUS = YYY
This message displays the VSD/Microprocessor inter-
nal ambient cabinet temperature and the cooling sys-
tem status (ON or OFF) at the time of the fault.
IGBT Baseplate Temperature
VSD IGBT BASEPLATE TEMPS T1 = XXX °F
T2 = XXX °F
This message displays the IGBT highest baseplate
temperature for 2 and 3 compressor units at the time of
the fault. 4 compressor units display temperatures for
1/3 (T1) and 2/4 (T2).
Precharge Signal Status and VSD Cooling
Status
VSD PRECHARGE SIGNAL = XXX
This display provides the state of the precharge signal,
where XXX is either ON or OFF at the time of the
fault.
Compressor #1 and #2, 105% FLA Motor
Overload Current Setting
VSD COMP 1 MOTOR OVERLOAD = XXX AMPS
COMP 2 MOTOR OVERLOAD = XXX AMPS
This message displays the setting of the VSD’s 100%
FLA potentiometer for Compressor #1 and #2 at the
time of the fault.
System Data
System #1 Pressures
SYS 1 PRESSURES OIL = XXXX PSIG
DISCHARGE = XXXX PSIG
This message displays the measured system oil and
discharge pressures at the time of the fault.
SYS 1 PRESSURES SUCTION = XXXX PSIG
CONDENSER LIQUID = XXXX PSIG
This message displays the measured system suction
and condenser liquid line pressure at the time of the
fault.
System # 1 Temperatures
SYS 1 TEMPERATURES OIL = XXX.X °F
EDUCTOR = XXX.X °F
This message displays the measured system oil and
eductor temperatures at the time of the fault.
SYS 1 CONDENSER LIQUID TEMP = XXX.X °F
SUBCOOLING = XXX.X SAT TEMP = XXX.X °F
This message displays the condenser liquid, liquid line
subcooling and saturated discharge temperatures at the
time of the fault.
SYS 1 DISCHARGE TEMP = XXX.X °F
SUPERHEAT = XXX.X SAT TEMP = XXX.X °F
This message displays the system discharge, discharge
superheat and saturated discharge temperatures at the
time of the fault.
Compressor Speed and Heater Status
SYS 1 COMPRESSOR SPEED = XXX.X %
HEATER = XXX.X °F
This message indicates the compressor speed in % and
the heater status at the time of the fault.
System #1 Motor Temperatures
SYS 1 MOTOR TEMPS T1 = XXX.X °F
T2 = XXX.X T3 = XXX.X °F
This message displays the System 1 motor thermistor
temperatures at the time of the fault.
Flash Tank Level and Economizer Position
SYS 1 FLASH TANK LEVEL Y 512 ADC
ECONOMIZER VALVE = XXX.X %
This message displays the flash tank level and the
economizer valve position in % at the time of the fault.
Condenser Subcooling and Condenser Drain
Valve Position
SYS 1 CONDENSER SUBCOOLING = XXX.X °F
CONDENSER DRAIN VALVE = XXX.X %
This message displays the condenser subcooling and
the Condenser Drain Valve position at the time of the
fault.
