SECTION 5 - TECHNICAL DATA
FORM QTC4-NM1
ISSUE DATE: 4/2/2018
TABLE 7 - OPTIONAL ONE-PASS EVAPORATOR
ALL DIMENSIONS - INCHES (MM)
QTC4
A,B C D
E
NOZZLE
SIZE
WATER
VOLUME.
GALLONS
(LITERS)
MINIMUM
CHILLED
WATER FLOW
RATE
GPM (L/S)
MAXIMUM
CHILLED
WATER FLOW
RATE
GPM (L/S)
MODEL
COND.
150 S
20.8
(528)
6.8
(173)
34.5
(876)
8
58
(220)
500
(32)
1970
(124)
165 H
20.8
(528)
29.2
(742)
56.1
(1425)
8
58
(220)
500
(32)
1970
(124)
175 P
20.8
(528)
34.9
(886)
70
(1778)
8
71
(269)
590
(37)
2190
(138)
185 S
19.8
(503)
17.7
(450)
56.8
(1443)
6
48
(182)
400
(25)
1230
(77)
185 H
19.8
(503)
61.5
(1562)
56.7
(1425)
6
48
(182)
400
(25)
1230
(77)
185 P
21
(533)
117.3
(2979)
56.1
(1425)
8
56
(220)
500
(32)
1970
(124)
175 C
20.8
(528)
1.7
(43)
38.1
(968)
8
71
(269)
590
(37)
2190
(138)
210 S
19.8
(503)
61.7
(1567)
56.8
(1443)
6
48
(182)
400
(25)
1230
(77)
210 H
20.8
(528)
34.9
(886)
70
(1778)
8
71
(269)
590
(37)
2190
(138)
210 P
21
(533)
78.9
(2044)
70
(1778)
8
71
(269)
590
(37)
2190
(138)
NOTE: Minimum Chilled Water Flow Rate is for full load selections; Variable Primary Flow ratings as low as 50% of the minimum are permitted.
Glycol limits are higher. Please contact your Quantech Sales Representative for ratings and further information.
