QUANTECH
72
SECTION 5 - TECHNICAL DATA
FORM QTC4-NM1
ISSUE DATE: 4/2/2018
ALL DIMENSIONS - INCHES (MM)
QTC4
A B C D
E
NOZZLE
SIZE
WATER
VOLUME
GALLONS
(LITERS)
MINIMUM
CHILLED
WATER FLOW
RATE
GPM (L/S)
MAXIMUM
CHILLED
WATER
FLOW RATE
GPM (L/S)
MODEL
COND.
150 S
15.1
(384)
26.5
(673)
6.8
(173)
34.5
(876)
5
58
(220)
170 (11) 650 (41)
165 H
15.1
(384)
26.5
(673)
29.2
(742)
56.1
(1425)
5
58
(220)
170 (11) 650 (41)
175 P
15.1
(384)
26.5
(673)
34.9
(886)
70
(1778)
6
71
(269)
200 (13) 780 (49)
185 S
25.5
(648)
25.5
(648)
17.7
(450)
56.8
(1443)
5
48
(182)
130 (8) 520 (33)
185 H
14.1
(358)
25.5
(648)
61.5
(1562)
56.7
(1440)
5
48
(182)
130 (8) 520 (33)
185 P
15.3
(389)
26.7
(678)
117.3
(2979)
56.1
(1425)
5
58
(220)
170 (11) 650 (41)
175 C
15.1
(384)
26.53
(674)
1.7
(43)
38.1
(968)
6
71
(269)
200 (13) 780 (49)
210 S
14.1
(358)
25.5
(648)
61.6
(1565)
58.8
(1494)
5
48
(182)
130 (8) 520 (33)
210 H
15.1
(384)
26.5
(673)
34.9
(886)
70
(1778)
6
71
(269)
200 (13) 780 (49)
210 P
15.3
(389)
26.7
(678)
78.9
(2004)
70.3
(1786)
6
71
(269)
200 (13) 780 (49)
TABLE 9 - OPTIONAL THREE-PASS REAR INLET/FRONT OUTLET EVAPORATOR
NOTE: Minimum Chilled Water Flow Rate is for full load selections; Variable Primary Flow ratings as low as 50% of the minimum are permitted.
Glycol limits are higher. Please contact your Quantech Sales Representative for ratings and further information.
